  6. One-Hole Compression Lug, 2 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Brown
Panduit One-Hole Compression Lug, 2 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Brown LCC2-12-Q - main

One-Hole Compression Lug, 2 AWG Max, 1 to 2 in Stud, Long Barrel, Copper, Brown

  • Mfr # LCC2-12-Q

  • Zoro # G0775448

product price:  $10.15
/ea

Key Features

For Wire Size
2 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
LCC2-12-Q
Zoro #
G0775448
UPC #
7498390287
Country of Origin
Mexico

Dimensions

For Wire Size
2 AWG
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
0.75 in
Width
3/4"
Cable Size
2 AWG
Length
4.51"
Overall Length
4.51 in
Tongue Thickness (mm)
2
Stud Hole Size (In.)
1 to 2
Copper Code Conductor Size (AWG)
2
Tongue Width (mm)
19.1
Overall Length (mm)
114.6
Barrel Length (In.)
1.16
Stud Hole Size (mm)
12.7
Tongue Thickness (In.)
0.08
Tongue Width (In.)
0.75
Barrel Length (mm)
29.5
Wire Strip Length (In.)
1.25
Wire Strip Length (mm)
31.8
Overall Length (In.)
4.51

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
10
Color Code
Brown
Standards
CSA certified to C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connector Type
Long Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant
Panduit Die Index Number
P33
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
Stud Hole Spacing (mm)
44.5
Tongue Type
Standard
Base Material
Copper
T & B Die Index Number
33
Burndy Die Index Number
10
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Stud Hole Spacing (In.)
1.75
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories

Description

Lug Compression Connector,No.2 AWG
