Shop PANDUIT

One-Hole Compression Lug, 2 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Brown

  • Mfr # LCDX2-12-E

  • Zoro # G204858282

product price:  $15.75
/ea

Key Features

For Wire Size
2 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCDX2-12-E
Zoro #
G204858282
UPC #
7498342373
Country of Origin
Mexico

Dimensions

For Wire Size
2 AWG
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
0.75 in
Overall Length
3.87 in
Overall Length (mm)
98.3
Copper Code Conductor Size (AWG)
2
Tongue Width (In.)
0.75
Stud Hole Size (In.)
1 to 2
Wire Strip Length (In.)
45246
Barrel Length (mm)
15
Class H Copper Flex Conductor Size (AWG)
2
Class G Copper Flex Conductor Size (AWG)
2
Class M Copper Flex Conductor Size (AWG)
2
DLO Copper Flex Conductor Size (AWG)
2
Stud Hole Size (mm)
12.7
Class K Copper Flex Conductor Size (AWG)
2
Wire Strip Length (mm)
17
Tongue Thickness (In.)
0.09
Tongue Width (mm)
19.1
Class I Copper Flex Conductor Size (AWG)
2
Overall Length (In.)
3.87
Barrel Length (In.)
0.59
Tongue Thickness (mm)
2.3

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
10
Color Code
Brown
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Hole Center to Center
44563
Tool Type
Compression Connectors - Lugs
Base Material
Copper
Tongue Type
Standard
Product Type
Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Panduit Die Index Number
P33
T & B Die Index Number
33
Burndy Die Index Number
10
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
Standards Met
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Stud Hole Spacing (mm)
44.5
Stud Hole Spacing (In.)
1.75
Product Class
Wire Termination
Number of Holes
1

Description

Two-hole, flex lug, #2 AWG wire, 1/2 stud hole, 1.75 hole spacing.
