One-Hole Compression Lug, 2 AWG Max, Standard Barrel, Copper, Brown
- Mfr # LCDX2-14AF-E
- Zoro # G904858223
product price:
$
17.15
/ea
Key Features
For Wire Size
2 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.70 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCDX2-14AF-E
- Zoro #
- G904858223
- UPC #
- 7498342686
- Country of Origin
- Mexico
- Item
- One-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Die Code
- 10
- Color Code
- Brown
- Hole Center to Center
- 44565
- Tool Type
- Compression Connectors - Lugs
- Maximum Voltage (kV)
- 35
- Base Material
- Copper
- Burndy Die Index Number
- 10
- Panduit Die Index Number
- P33
- UL Temperature Rating (°C)
- 90
- Stud Hole Spacing (mm)
- 16
- Product Type
- Compression Connectors - Lugs
- Stud Hole Spacing (In.)
- 0.63
- Tongue Type
- Standard
- Finish/Coating
- Tin-Plated
- Product Class
- Wire Termination
- Number of Holes
- 1
Dimensions
- For Wire Size
- 2 AWG
- Barrel Size
- Standard
- Tongue Width
- 0.70 in
- Overall Length
- 1.94 in
- Overall Length (mm)
- 49.3
- Stud Hole Size (mm)
- 6.4
- Class I Copper Flex Conductor Size (AWG)
- 2
- Class H Copper Flex Conductor Size (AWG)
- 2
- Class K Copper Flex Conductor Size (AWG)
- 2
- Barrel Length (mm)
- 15
- Tongue Width (mm)
- 17.8
- Class G Copper Flex Conductor Size (AWG)
- 2
- Tongue Width (In.)
- 0.7
- Overall Length (In.)
- 1.94
- Stud Hole Size (In.)
- 44930
- Class M Copper Flex Conductor Size (AWG)
- 2
- Barrel Length (In.)
- 0.59
- Copper Code Conductor Size (AWG)
- 2
- DLO Copper Flex Conductor Size (AWG)
- 2
- Tongue Thickness (mm)
- 2.8
- Tongue Thickness (In.)
- 0.11
- Wire Strip Length (mm)
- 17
Description
Two-hole, flex lug, #2 AWG wire, 1/4 stud hole, .63 hole spacing, 90° angle tongue.
