  11. One-Hole Compression Lug, 2/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Black
Panduit One-Hole Compression Lug, 2/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Black LCA2/0-12F-X - main

One-Hole Compression Lug, 2/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Black

  • Mfr # LCA2/0-12F-X

  • Zoro # G0771491

product price: $11.63
/ea

Key Features

Cable Size
2/0 AWG
Connector Type
Standard Barrel
Width
0.85"
Material
Copper
Length
1.91"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCA2/0-12F-X
Zoro #
G0771491
UPC #
7498355927
Country of Origin
Mexico

Dimensions

Cable Size
2/0 AWG
Width
0.85"
Length
1.91"
Overall Length
1.91 in
Overall Length (In.)
1.91
Tongue Width (In.)
0.85
Stud Hole Size (mm)
12.7
Stud Hole Size (In.)
1 to 2
Tongue Thickness (mm)
3.3
Wire Strip Length (mm)
27
Overall Length (mm)
48.5
Wire Strip Length (In.)
1.06
Copper Code Conductor Size (AWG)
36557
Tongue Width (mm)
21.6
Barrel Length (In.)
0.98
Tongue Thickness (In.)
0.13
Barrel Length (mm)
24.9
Tongue Width
0.85 in
Barrel Size
Standard
For Wire Size
2/0 AWG
For Stud Size
1 to 2 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Black
Item
One-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
13
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant, 90° Angled Connector
Maximum Voltage (kV)
35
Tongue Angle
90 Degrees Angled
Base Material
Copper
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plated
Panduit Die Index Number
P45
Burndy Die Index Number
13
Product Name
Terminal Connector
Product Material
Copper
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,2/0 AWG
