  11. One-Hole Compression Lug, 2/0 AWG Max, 1/2 in Stud, Standard Barrel, Copper, Black
Panduit One-Hole Compression Lug, 2/0 AWG Max, 1/2 in Stud, Standard Barrel, Copper, Black LCAX2/0-56-X - main

One-Hole Compression Lug, 2/0 AWG Max, 1/2 in Stud, Standard Barrel, Copper, Black

  • Mfr # LCAX2/0-56-X

  • Zoro # G0773829

product price: $9.43
/ea

Key Features

Cable Size
2/0 AWG
Connector Type
Standard Barrel
Width
0.96"
Material
Copper
Length
1.97"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX2/0-56-X
Zoro #
G0773829
UPC #
7498343536
Country of Origin
Mexico

Dimensions

Cable Size
2/0 AWG
Width
0.96"
Length
1.97"
Overall Length
1.97 in
Inside Diameter (In.)
0.51
Tongue Thickness (In.)
0.13
Wire Strip Length (mm)
22.2
Barrel Length (In.)
0.83
Tongue Width (In.)
0.96
Tongue Width (mm)
24.4
DLO Copper Flex Conductor Size (AWG)
36557
Wire Strip Length (In.)
45115
Class G Copper Flex Conductor Size (AWG)
36557
Class H Copper Flex Conductor Size (AWG)
36557
Copper Code Conductor Size (AWG)
36557
Class M Copper Flex Conductor Size (AWG)
36557
Inside Diameter (mm)
12.95
Class K Copper Flex Conductor Size (AWG)
36557
Class I Copper Flex Conductor Size (AWG)
36557
Outer Diameter (In.)
0.64
Overall Length (mm)
50
Stud Hole Size (mm)
7.9
Overall Length (In.)
1.97
Barrel Length (mm)
21.1
Outer Diameter (mm)
16.25
Tongue Thickness (mm)
3.3
Stud Hole Size (In.)
45062
Tongue Width
0.96 in
For Wire Size
2/0 AWG
Barrel Size
Standard
For Stud Size
1/2 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Black
Item
One-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
13
Features
Angled Connector, Corrosion Resistant
Burndy Die Index Number
13
Tongue Type
Standard
Lug Type
1 Stud Hole Lug
Base Material
Copper
Tongue Angle
Straight
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
Panduit Die Index Number
P45
UL Temperature Rating (°C)
90
Finish/Coating
Tin-Plated
T & B Die Index Number
13
Product Material
Copper
Connector Plating
Tin
Product Name
Terminal Connector
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories
Number of Holes
1
For Conductor Material
Copper

Description

Lug Compression Connector,2/0 AWG
