  11. One-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black
Panduit One-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black LCD2/0-38D-X - main

One-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black

  • Mfr # LCD2/0-38D-X

  • Zoro # G0777292

product price: $11.69
/ea

Key Features

Cable Size
2/0 AWG
Connector Type
Standard Barrel
Width
0.85"
Material
Copper
Length
3.14"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD2/0-38D-X
Zoro #
G0777292
UPC #
7498338326
Country of Origin
Mexico

Dimensions

Cable Size
2/0 AWG
Width
0.85"
Length
3.14"
Overall Length
3.14 in
Stud Hole Size (mm)
9.5
Stud Hole Size (In.)
44993
Tongue Thickness (mm)
3.3
Tongue Width (In.)
0.85
Barrel Length (mm)
24.9
Wire Strip Length (In.)
1.0625
Copper Code Conductor Size (AWG)
36557
Overall Length (In.)
3.14
Tongue Width (mm)
21.6
Overall Length (mm)
79.8
Barrel Length (In.)
0.98
Tongue Thickness (In.)
0.13
Wire Strip Length (mm)
27
For Wire Size
2/0 AWG
Tongue Width
0.85 in
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Black
Item
One-Hole Compression Lug
Die Code
13
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Features
Corrosion Resistant
Connection Material
Tin
Connection Type
1 x Terminal
Stud Hole Spacing (In.)
1
Base Material
Copper
Tongue Angle
Straight
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
Panduit Die Index Number
P45
T & B Die Index Number
45
Stud Hole Spacing (mm)
25.4
Burndy Die Index Number
13
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories
Number of Holes
1
For Conductor Material
Copper

Description

Lug Compression Connector,2/0 AWG
