One-Hole Compression Lug, 250 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Yellow
- Mfr # LCB250-12-X
- Zoro # G0774599
product price:Â
$
14.79
/ea
Key Features
For Wire Size
250 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCB250-12-X
- Zoro #
- G0774599
- UPC #
- 7498390145
- Country of Origin
- Mexico
- Item
- One-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Tongue Angle
- Straight
- Color Code
- Yellow
- Standards
- C22.2 No. 65-13, 486A-486B File #E52164
- Connector Type
- Long Barrel
- Features
- Angled Connector, Corrosion Resistant
- Connection Material
- Tin
- Connection Type
- 1 x Terminal
- Product Type
- Copper Compression Connectors - Lugs
- UL Temperature Rating (°C)
- 90
- Base Material
- Copper
- Maximum Voltage (kV)
- 35
- Tongue Type
- Standard
- Finish/Coating
- Tin-Plated
- Panduit Die Index Number
- P62
- Burndy Die Index Number
- 16
- Connector Plating
- Tin
- Connector Details
- 1 x Terminal
- Product Material
- Copper
- Product Name
- Terminal Connector
- Product Class
- Lugs, Splices, Split Bolts & Accessories
Dimensions
- For Wire Size
- 250 kcmil
- For Stud Size
- 1 to 2 in
- Barrel Size
- Long
- Tongue Width
- 1.17 in
- Width
- 1.17 in
- Length
- 3.32"
- Cable Size
- 250 kcmil
- Overall Length
- 3.32 in
- Overall Length (In.)
- 3.32
- Wire Strip Length (In.)
- 1.69
- Barrel Length (mm)
- 40.9
- Overall Length (mm)
- 84.3
- Tongue Thickness (mm)
- 3.6
- Copper Code Conductor Size (kcmil)
- 250
- Tongue Width (mm)
- 29.7
- Stud Hole Size (mm)
- 12.7
- Tongue Width (In.)
- 1.17
- Stud Hole Size (In.)
- 1 to 2
- Wire Strip Length (mm)
- 42.9
- Barrel Length (In.)
- 1.61
- Tongue Thickness (In.)
- 0.14
Description
Lug Compression Connector,250 Kcmil
