  11. One-Hole Compression Lug, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange
Panduit One-Hole Compression Lug, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange LCAX3/0-12H-X - main

One-Hole Compression Lug, 3/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Orange

  • Mfr # LCAX3/0-12H-X

  • Zoro # G0773941

product price: $15.29
/ea

Key Features

Cable Size
3/0 AWG
Connector Type
Standard Barrel
Width
1.06"
Material
Copper
Length
2.08"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX3/0-12H-X
Zoro #
G0773941
UPC #
7498343555
Country of Origin
Mexico

Dimensions

Cable Size
3/0 AWG
Width
1.06"
Length
2.08"
Overall Length
2.08 in
Tongue Width (In.)
1.06
Wire Strip Length (In.)
1
Class M Copper Flex Conductor Size (AWG)
36586
Class I Copper Flex Conductor Size (AWG)
36586
Class G Copper Flex Conductor Size (AWG)
36586
Class H Copper Flex Conductor Size (AWG)
36586
Overall Length (In.)
2.08
Tongue Thickness (In.)
0.14
DLO Copper Flex Conductor Size (AWG)
36586
Tongue Width (mm)
26.9
Copper Code Conductor Size (AWG)
36586
Wire Strip Length (mm)
25.4
Class K Copper Flex Conductor Size (AWG)
36586
Stud Hole Size (In.)
1 to 2
Stud Hole Size (mm)
12.7
Barrel Length (In.)
0.91
Barrel Length (mm)
23.1
Overall Length (mm)
52.8
Tongue Thickness (mm)
3.6
Tongue Width
1.06 in
For Stud Size
1 to 2 in
Barrel Size
Standard
For Wire Size
3/0 AWG

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Orange
Item
One-Hole Compression Lug
Die Code
14
Connection Type
1 x Terminal
Connection Material
Tin
Features
45° Angled Connector, Corrosion Resistant
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Base Material
Copper
Panduit Die Index Number
P50
Tongue Type
Standard
Tongue Angle
45 Degrees Angled
Finish/Coating
Tin-Plated
Burndy Die Index Number
14
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,3/0 AWG
