  6. One-Hole Compression Lug, 3/0 AWG Max, Long Barrel, Copper, Orange
Panduit One-Hole Compression Lug, 3/0 AWG Max, Long Barrel, Copper, Orange LCBX3/0-38-X - main

One-Hole Compression Lug, 3/0 AWG Max, Long Barrel, Copper, Orange

  • Mfr # LCBX3/0-38-X

  • Zoro # G0775107

product price:  $15.19
/ea

Key Features

For Wire Size
3/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Long
Tongue Width
1.06 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCBX3/0-38-X
Zoro #
G0775107
UPC #
7498343712
Country of Origin
Mexico

Dimensions

For Wire Size
3/0 AWG
Barrel Size
Long
Tongue Width
1.06 in
Width
1.06 in
Length
2.81 in
Cable Size
3/0 AWG
Overall Length
2.81 in
Barrel Length (mm)
39.6
Tongue Width (In.)
1.06
DLO Copper Flex Conductor Size (AWG)
36586
Overall Length (mm)
71.4
Class M Copper Flex Conductor Size (AWG)
36586
Class K Copper Flex Conductor Size (AWG)
36586
Barrel Length (In.)
1.56
Tongue Thickness (In.)
0.14
Class G Copper Flex Conductor Size (AWG)
36586
Wire Strip Length (mm)
41
Tongue Thickness (mm)
3.6
Overall Length (In.)
2.81
Copper Code Conductor Size (AWG)
36586
Tongue Width (mm)
26.9
Stud Hole Size (mm)
9.5
Stud Hole Size (In.)
44993
Class I Copper Flex Conductor Size (AWG)
36586
Class H Copper Flex Conductor Size (AWG)
36586

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
14
Color Code
Orange
Connector Type
Long Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, Angled Connector
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Panduit Die Index Number
P50
Base Material
Copper
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Burndy Die Index Number
14
Finish/Coating
Tin-Plated
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Wire Termination

Description

Lug Compression Connector,3/0 AWG
