  11. One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange
Panduit One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange LCAX3/0-14-X - main

One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange

  • Mfr # LCAX3/0-14-X

  • Zoro # G0421539

product price: $11.99
/ea

Key Features

For Wire Size
3/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.06 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX3/0-14-X
Zoro #
G0421539
UPC #
7498343545
Country of Origin
Mexico

Dimensions

For Wire Size
3/0 AWG
Barrel Size
Standard
Tongue Width
1.06 in
Cable Size
3/0 AWG
Width
1.06"
Length
2.08"
Overall Length
2.08 in
Wire Strip Length (In.)
1
Class I Copper Flex Conductor Size (AWG)
36586
Class K Copper Flex Conductor Size (AWG)
36586
Copper Code Conductor Size (AWG)
36586
Class H Copper Flex Conductor Size (AWG)
36586
Stud Hole Size (mm)
6.4
Wire Strip Length (mm)
25.4
Stud Hole Size (In.)
44930
Barrel Length (In.)
0.91
Barrel Length (mm)
23.1
Tongue Width (mm)
26.9
Overall Length (In.)
2.08
Class G Copper Flex Conductor Size (AWG)
36586
Tongue Width (In.)
1.06
Class M Copper Flex Conductor Size (AWG)
36586
DLO Copper Flex Conductor Size (AWG)
36586
Tongue Thickness (mm)
3.6
Tongue Thickness (In.)
0.14
Overall Length (mm)
52.8

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
14
Color Code
Orange
Connector Type
Standard Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Angled Connector, Corrosion Resistant
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
Panduit Die Index Number
P50
Finish/Coating
Tin-Plated
Burndy Die Index Number
14
Base Material
Copper
Tongue Type
Standard
UL Temperature Rating (°C)
90
Connector Details
1 x Terminal
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Product Class
Wire Termination

Description

One-hole, flex lug, 3/0 AWG wire, 1/4 stud hole.
