  11. One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange
Panduit One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange LCAX3/0-38F-X - main

One-Hole Compression Lug, 3/0 AWG Max, Standard Barrel, Copper, Orange

  • Mfr # LCAX3/0-38F-X

  • Zoro # G0773978

product price: $15.19
/ea

Key Features

Cable Size
3/0 AWG
Connector Type
Standard Barrel
Width
1.06"
Material
Copper
Length
1.84"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX3/0-38F-X
Zoro #
G0773978
UPC #
7498343553
Country of Origin
Mexico

Dimensions

Cable Size
3/0 AWG
Width
1.06"
Length
1.84"
Overall Length
1.84 in
Class I Copper Flex Conductor Size (AWG)
36586
Tongue Thickness (mm)
3.6
Tongue Width (In.)
1.06
Class M Copper Flex Conductor Size (AWG)
36586
Stud Hole Size (In.)
44993
Copper Code Conductor Size (AWG)
36586
Class K Copper Flex Conductor Size (AWG)
36586
Barrel Length (mm)
23.1
Class G Copper Flex Conductor Size (AWG)
36586
Overall Length (In.)
1.84
Stud Hole Size (mm)
9.5
Barrel Length (In.)
0.91
Tongue Width (mm)
26.9
Tongue Thickness (In.)
0.14
Wire Strip Length (mm)
25.4
DLO Copper Flex Conductor Size (AWG)
36586
Overall Length (mm)
46.8
Wire Strip Length (In.)
1
Class H Copper Flex Conductor Size (AWG)
36586
For Wire Size
3/0 AWG
Barrel Size
Standard
Tongue Width
1.06 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Orange
Item
One-Hole Compression Lug
Die Code
14
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant, 90° Angled Connector
T & B Die Index Number
50
UL Temperature Rating (°C)
90
Finish/Coating
Tin-Plated
Product Type
Copper Compression Connectors - Lugs
Panduit Die Index Number
P50
Tongue Type
Standard
Base Material
Copper
Tongue Angle
90 Degrees Angled
Burndy Die Index Number
14
Maximum Voltage (kV)
35
Connector Details
1 x Terminal
Connector Plating
Tin
Product Material
Copper
Product Name
Terminal Connector
Product Class
Wire Termination
For Conductor Material
Copper

Description

Lug Compression Connector,3/0 AWG
