Shop PANDUIT

One-Hole Compression Lug, 350 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Blue

  • Mfr # LCAX350-12-6
  • Zoro # G0413172
product price:
$
23.15
/ea

Key Features

For Wire Size
350 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCAX350-12-6
Zoro #
G0413172
UPC #
7498343591
Country of Origin
Mexico

Dimensions

For Wire Size
350 kcmil
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
1.54 in
Width
1.54"
Cable Size
350 kcmil
Length
3.09"
Overall Length
3.09 in
Tongue Thickness (mm)
5.6
Stud Hole Size (mm)
12.7
Outer Diameter (In.)
1.06
Class H Copper Flex Conductor Size (kcmil)
350
Outer Diameter (mm)
26.92
Wire Strip Length (mm)
34.9
Inside Diameter (In.)
0.84
Tongue Width (mm)
39.1
Wire Strip Length (In.)
39450
Stud Hole Size (In.)
1 to 2
Tongue Width (In.)
1.54
Class G Copper Flex Conductor Size (kcmil)
350
Inside Diameter (mm)
21.33
Overall Length (mm)
78.5
Barrel Length (mm)
32.8
Barrel Length (In.)
1.29
Class I Copper Flex Conductor Size (kcmil)
350
Class K Copper Flex Conductor Size (kcmil)
350
DLO Copper Flex Conductor Size (kcmil)
373.7
Tongue Thickness (In.)
0.22
Class M Copper Flex Conductor Size (kcmil)
350
Overall Length (In.)
3.09

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
19
Color Code
Blue
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant, Angled Connector
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
Lug Type
1 Stud Hole Lug
T & B Die Index Number
19
Base Material
Copper
Panduit Die Index Number
P76
Burndy Die Index Number
19
Tongue Type
Standard
Finish/Coating
Tin-Plated
UL Temperature Rating (°C)
90
Product Material
Copper
Product Name
Terminal Connector
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories
Number of Holes
1

Description

One-hole, flex lug, 350 kcmil cable, 1/2 stud hole.

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
