One-Hole Compression Lug, 4 AWG Max, Long Barrel, Copper, Gray
Mfr # LCC4-10AWF-L
Zoro # G504858999
product price: $13.15
/eaKey Features
For Wire Size
4 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Long
Tongue Width
0.55 in
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption
Specifications
Product Information
- MFR #
- LCC4-10AWF-L
- Zoro #
- G504858999
- UPC #
- 7498390423
- Country of Origin
- Mexico
Dimensions
- For Wire Size
- 4 AWG
- Barrel Size
- Long
- Tongue Width
- 0.55 in
- Overall Length
- 1.65 in
- Barrel Length
- 1.05
- Tongue Width - Wire Connector
- 0.55
- Stud Hole Size (In.)
- 0.19
- Stud Hole Size (mm)
- 4.8
- Overall Length (In.)
- 1.65
- Tongue Thickness (mm)
- 2.3
- Barrel Length (mm)
- 26.7
- Wire Strip Length (In.)
- 1.13
- Tongue Thickness (In.)
- 0.09
- Tongue Width (mm)
- 14
- Wire Strip Length (mm)
- 28.6
- Tongue Width (In.)
- 0.55
- Barrel Length (In.)
- 1.05
- Overall Length (mm)
- 41.9
- Copper Code Conductor Size (AWG)
- 4
Description
Two-hole, long barrel lug with window, #4 — #3 AWG STR, #2 AWG SOL wire, #10 stud hole, .63 hole spacing, 90° angle tongue.
