  6. One-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple LCA4/0-12F-X - main

One-Hole Compression Lug, 4/0 AWG Max, 1 to 2 in Stud, Standard Barrel, Copper, Purple

  • Mfr # LCA4/0-12F-X

  • Zoro # G0771613

product price:  $18.49
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Standard
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
LCA4/0-12F-X
Zoro #
G0771613
UPC #
7498355945
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
For Stud Size
1 to 2 in
Barrel Size
Standard
Tongue Width
1.06 in
Width
1.06"
Length
2.07"
Cable Size
4/0 AWG
Overall Length
2.07 in
Barrel Length (mm)
30.2
Barrel Length (In.)
1.19
Overall Length (mm)
52.6
Copper Code Conductor Size (AWG)
36617
Overall Length (In.)
2.07
Stud Hole Size (In.)
1 to 2
Stud Hole Size (mm)
12.7
Tongue Width (mm)
26.9
Wire Strip Length (mm)
31.8
Tongue Thickness (In.)
0.14
Wire Strip Length (In.)
1.25
Tongue Width (In.)
1.06
Tongue Thickness (mm)
3.6

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
90 Degrees Angled
Die Code
15
Color Code
Purple
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
90° Angled Connector, Corrosion Resistant
Panduit Die Index Number
P54
Maximum Voltage (kV)
35
Base Material
Copper
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
15
Tongue Type
Standard
UL Temperature Rating (°C)
90
Finish/Coating
Tin-Plated
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Wire Termination

Description

Lug Compression Connector,4/0 AWG
