  11. One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple LCAX4/0-14-X - main

One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-14-X

  • Zoro # G0425054

product price: $14.59
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.19 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCAX4/0-14-X
Zoro #
G0425054
UPC #
7498344763
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
Barrel Size
Standard
Tongue Width
1.19 in
Length
2.3"
Width
1.19"
Cable Size
4/0 AWG
Overall Length
2.3 in
Tongue Width (In.)
1.19
DLO Copper Flex Conductor Size (AWG)
36617
Inside Diameter (In.)
0.65
Class I Copper Flex Conductor Size (AWG)
36617
Copper Code Conductor Size (AWG)
36617
Wire Strip Length (mm)
26.9
Outer Diameter (In.)
0.81
Outer Diameter (mm)
20.57
Class G Copper Flex Conductor Size (AWG)
36617
Tongue Thickness (mm)
4.1
Class H Copper Flex Conductor Size (AWG)
36617
Class M Copper Flex Conductor Size (AWG)
36617
Barrel Length (In.)
1.03
Stud Hole Size (mm)
6.4
Inside Diameter (mm)
16.51
Wire Strip Length (In.)
42370
Tongue Thickness (In.)
0.16
Stud Hole Size (In.)
44930
Class K Copper Flex Conductor Size (AWG)
36617
Overall Length (In.)
2.3
Barrel Length (mm)
26.2
Tongue Width (mm)
30.2
Overall Length (mm)
58.4

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
15
Color Code
Purple
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Standard Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
Corrosion Resistant, Angled Connector
T & B Die Index Number
15
Base Material
Copper
Product Type
Copper Compression Connectors - Lugs
Lug Type
1 Stud Hole Lug
Tongue Type
Standard
UL Temperature Rating (°C)
90
Panduit Die Index Number
P54
Maximum Voltage (kV)
35
Burndy Die Index Number
15
Finish/Coating
Tin-Plated
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Wire Termination

Description

Std Flex Lug,4/0 Awg,.25in,Wdw
