  6. One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple LCAX4/0-58F-X - main

One-Hole Compression Lug, 4/0 AWG Max, Standard Barrel, Copper, Purple

  • Mfr # LCAX4/0-58F-X

  • Zoro # G0774020

product price:  $21.19
/ea

Key Features

For Wire Size
4/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.19 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCAX4/0-58F-X
Zoro #
G0774020
UPC #
7498343569
Country of Origin
Mexico

Dimensions

For Wire Size
4/0 AWG
Barrel Size
Standard
Tongue Width
1.19 in
Width
1.19 in
Cable Size
4/0 AWG
Length
2.39 in
Overall Length
2.39 in
Tongue Thickness (In.)
0.16
Wire Strip Length (mm)
27
Class K Copper Flex Conductor Size (AWG)
36617
Barrel Length (mm)
26.2
Tongue Thickness (mm)
4.1
Class H Copper Flex Conductor Size (AWG)
36617
Overall Length (mm)
60.7
Stud Hole Size (In.)
45054
DLO Copper Flex Conductor Size (AWG)
36617
Overall Length (In.)
2.39
Class G Copper Flex Conductor Size (AWG)
36617
Class M Copper Flex Conductor Size (AWG)
36617
Copper Code Conductor Size (AWG)
36617
Tongue Width (In.)
1.19
Tongue Width (mm)
30.2
Class I Copper Flex Conductor Size (AWG)
36617
Stud Hole Size (mm)
15.9
Barrel Length (In.)
1.03

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
90 Degrees Angled
Die Code
15
Color Code
Purple
Connector Type
Standard Barrel
Connection Material
Tin
Connection Type
1 x Terminal
Features
90° Angled Connector, Corrosion Resistant
Base Material
Copper
Burndy Die Index Number
15
Product Type
Copper Compression Connectors - Lugs
Tongue Type
Standard
Maximum Voltage (kV)
35
Finish/Coating
Tin-Plated
UL Temperature Rating (°C)
90
Panduit Die Index Number
P54
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Material
Copper
Connector Plating
Tin
Product Class
Wire Termination

Description

Lug Compression Connector,4/0 AWG
