One-Hole Compression Lug, 6 AWG Max, Standard Barrel, Copper, Blue
Mfr # LCAX6-56F-L
Zoro # G204858541
product price:
$
3.89
/ea
Sold in multiples of 2 for $7.78
Key Features
For Wire Size
6 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.56 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- LCAX6-56F-L
- Zoro #
- G204858541
- UPC #
- 7498343377
- Country of Origin
- Mexico
Dimensions
- For Wire Size
- 6 AWG
- Barrel Size
- Standard
- Tongue Width
- 0.56 in
- Overall Length
- 1.15 in
- Barrel Length
- 0.48
- Overall Length (mm)
- 29.2
- Tongue Width (In.)
- 0.56
- Wire Strip Length (mm)
- 14.3
- Class H Copper Flex Conductor Size (AWG)
- 6
- Copper Code Conductor Size (AWG)
- 6
- Class K Copper Flex Conductor Size (AWG)
- 6
- Tongue Thickness (In.)
- 0.07
- Barrel Length (mm)
- 12.2
- Stud Hole Size (In.)
- 45062
- Overall Length (In.)
- 1.15
- Tongue Width (mm)
- 14.2
- DLO Copper Flex Conductor Size (AWG)
- 6
- Class M Copper Flex Conductor Size (AWG)
- 6
- Tongue Thickness (mm)
- 1.8
- Class G Copper Flex Conductor Size (AWG)
- 6
- Barrel Length (In.)
- 0.48
- Stud Hole Size (mm)
- 7.9
- Class I Copper Flex Conductor Size (AWG)
- 6
Description
One-hole, flex lug, #6 AWG wire, 5/16 stud hole., 90° angle tongue.
