Panduit One-Hole Compression Lug, 6 AWG Max, Standard Barrel, Copper, Blue LCD6-14B-L - main

One-Hole Compression Lug, 6 AWG Max, Standard Barrel, Copper, Blue

  • Mfr # LCD6-14B-L

  • Zoro # G0777618

product price: $6.95
/ea

Key Features

Cable Size
6 AWG
Connector Type
Standard Barrel
Width
0.48"
Material
Copper
Length
2.36"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD6-14B-L
Zoro #
G0777618
UPC #
7498338311
Country of Origin
Mexico

Dimensions

Cable Size
6 AWG
Width
0.48"
Length
2.36"
Overall Length
2.36 in
Barrel Length (mm)
20.6
Overall Length (In.)
2.36
Tongue Thickness (mm)
2
Tongue Width (mm)
12.2
Tongue Width (In.)
0.48
Wire Strip Length (In.)
45115
Stud Hole Size (mm)
6.4
Tongue Thickness (In.)
0.08
Barrel Length (In.)
0.81
Overall Length (mm)
59.9
Wire Strip Length (mm)
22.2
Stud Hole Size (In.)
44930
Copper Code Conductor Size (AWG)
6
For Wire Size
6 AWG
Tongue Width
0.48 in
Barrel Size
Standard

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Blue
Item
One-Hole Compression Lug
Die Code
7
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Features
Corrosion Resistant
Connection Type
1 x Terminal
Connection Material
Tin
Burndy Die Index Number
7
Tongue Angle
Straight
Base Material
Copper
Maximum Voltage (kV)
35
Product Type
Copper Compression Connectors - Lugs
Stud Hole Spacing (In.)
0.75
Stud Hole Spacing (mm)
19.1
UL Temperature Rating (°C)
90
T & B Die Index Number
24
Finish/Coating
Tin-Plated
Panduit Die Index Number
24
Tongue Type
Standard
Product Name
Terminal Connector
Connector Plating
Tin
Product Material
Copper
Connector Details
1 x Terminal
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,No.6 AWG
