One-Hole Compression Lug, 750 kcmil Max, 1 to 2 in Stud, Standard Barrel, Aluminum, Red, 20 PK

  • Mfr # LAB750-12-20R

  • Zoro # G604859308

product price:  $1,642.99
/pk 20, $82.15/ea
Free Shipping & Returns

Key Features

Material
Aluminum
Color Code
Red
Standards
UL/CSA
Overall Length
8.25 in
Die Code
301
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LAB750-12-20R
Zoro #
G604859308
UPC #
61305677585
Country of Origin
Mexico

Dimensions

Overall Length
8.25 in
Outside Dia.
1.59
Stud Hole Size (mm)
12.7
Barrel Length (mm)
87.37
Aluminum Conductor Size (kcmil)
750
Outer Diameter (In.)
1.59
Overall Length (mm)
209.55
Tongue Thickness (mm)
13.71
Barrel Length (In.)
3.44
Tongue Width (In.)
1.74
Wire Strip Length (In.)
3.4375
Tongue Thickness (In.)
0.54
Copper Code Conductor Size (kcmil)
750
Inside Diameter (In.)
1.03
Wire Strip Length (mm)
87.31
Outer Diameter (mm)
40.38
Overall Length (In.)
8.25
Inside Diameter (mm)
26.16
Tongue Width (mm)
44.19
Stud Hole Size (In.)
1 to 2
Tongue Width
1.74 in
For Wire Size
750 kcmil
Barrel Size
Standard
For Stud Size
1 to 2 in

Details

Material
Aluminum
Color Code
Red
Standards
UL/CSA
Die Code
301
Item
One-Hole Compression Lug
Tool Type
Aluminum Compression Lugs
Hole Center to Center
0.95 in
Product Type
Aluminum Compression Lugs
Maximum Voltage (kV)
35
Tongue Angle
Straight
UL Temperature Rating (°C)
90
Base Material
Aluminum
Stud Hole Spacing (mm)
44.45
Stud Hole Spacing (In.)
1.75
Burndy Die Index Number
301
Tongue Type
Standard
Finish/Coating
Tin-Plated
CSA Temperature Rating (°C)
90
Panduit Die Index Number
P125
Number of Holes
1
For Conductor Material
Aluminum

Description

The LAB750-12-20R Aluminum Compression Connector Lug, two-hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90°C.
