One-Hole Compression Lug, Standard Barrel, Copper, Blue
- Mfr # LCAX350-56-6
- Zoro # G304858793
product price:Â
$
25.39
/ea
Key Features
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.54 in
Tongue Angle
Straight
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCAX350-56-6
- Zoro #
- G304858793
- UPC #
- 7498344781
- Country of Origin
- Mexico
- Item
- One-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Tongue Angle
- Straight
- Die Code
- 19
- Color Code
- Blue
- Tool Type
- Tin-Plated Copper Compression Connectors - Lugs
- Hole Center to Center
- 44687
- Tongue Style
- Standard
- Panduit Die Index Number
- P76
- Product Type
- Copper Compression Connectors - Lugs
- Maximum Voltage (kV)
- 35
- Tongue Type
- Standard
- Base Material
- Copper
- Finish/Coating
- Tin-Plated
- UL Temperature Rating (°C)
- 90
- Burndy Die Index Number
- 19
- Product Class
- Wire Termination
Dimensions
- Barrel Size
- Standard
- Tongue Width
- 1.54 in
- Overall Length
- 2.93 in
- Barrel Length
- 1.29
- Tongue Width (In.)
- 1.54
- Class H Copper Flex Conductor Size (kcmil)
- 350
- Wire Strip Length (mm)
- 34.9
- Barrel Length (In.)
- 1.29
- Class G Copper Flex Conductor Size (kcmil)
- 350
- Overall Length (mm)
- 74.4
- Overall Length (In.)
- 2.93
- Class I Copper Flex Conductor Size (kcmil)
- 350
- Tongue Thickness (In.)
- 0.22
- Stud Hole Size (mm)
- 7.9
- Barrel Length (mm)
- 32.8
- Class M Copper Flex Conductor Size (kcmil)
- 350
- Tongue Width (mm)
- 39.1
- Class K Copper Flex Conductor Size (kcmil)
- 350
- Stud Hole Size (In.)
- 45052
- Tongue Thickness (mm)
- 5.6
Description
One-hole, flex lug, 350 kcmil cable, 5/16 stud hole.
