One-Hole Compression Lug, Standard Barrel, Copper, Orange

  • Mfr # LCAX3/0-14-T

  • Zoro # G904858322

product price:
$
12.79
/ea

Key Features

For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
1.06 in
Tongue Angle
Straight
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCAX3/0-14-T
Zoro #
G904858322
UPC #
61305644892
Country of Origin
Mexico

Dimensions

Barrel Size
Standard
Tongue Width
1.06 in
Overall Length
2.08 in
Barrel Length
0.91
DLO Copper Flex Conductor Size (AWG)
36586
Copper Code Conductor Size (AWG)
36586
Overall Length (In.)
2.08
Class H Copper Flex Conductor Size (AWG)
36586
Tongue Thickness (mm)
3.556
Class G Copper Flex Conductor Size (AWG)
36586
Stud Hole Size (In.)
44930
Tongue Width (In.)
1.06
Class I Copper Flex Conductor Size (AWG)
36586
Wire Strip Length (mm)
25.4
Tongue Width (mm)
26.924
Class K Copper Flex Conductor Size (AWG)
36586
Class M Copper Flex Conductor Size (AWG)
36586
Overall Length (mm)
52.8
Stud Hole Size (mm)
6.35
Tongue Thickness (In.)
0.14
Barrel Length (mm)
23.1
Barrel Length (In.)
0.91
Wire Strip Length (In.)
1

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
14
Color Code
Orange
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Hole Center to Center
44565
Tool Type
Tin-Plated Copper Compression Connectors - Lugs
Product Type
Copper Compression Connectors - Lugs
Tongue Type
Standard
Panduit Die Index Number
P50
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
Base Material
Copper
T & B Die Index Number
50
Finish/Coating
Tin-Plated
Burndy Die Index Number
14

Description

The LCAX3/0-14-T Tin-Plated Copper Compression Lug, one-hole, standard barrel, has color-coded barrels marked with Panduit and specified competitor die index numbers for proper crimp die selection. An inspection window aids to visually assure full conductor insertion, and the tin-plate material helps to inhibit corrosion. UL Listed and CSA Certified to 35 KV and temperature rated to 90°C.
