  6. One-Hole Compression Lug, Standard Barrel, Copper, Purple
Panduit One-Hole Compression Lug, Standard Barrel, Copper, Purple LCAN4/0-56-X - main

One-Hole Compression Lug, Standard Barrel, Copper, Purple

  • Mfr # LCAN4/0-56-X

  • Zoro # G804859825

product price:  $15.29
/ea

Key Features

For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.71 in
Tongue Angle
Straight
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCAN4/0-56-X
Zoro #
G804859825
UPC #
7498344480
Country of Origin
Mexico

Dimensions

Barrel Size
Standard
Tongue Width
0.71 in
Tongue Width - Wire Connector
0.71
Overall Length
2.4 in
Barrel Length
1.19
Wire Strip Length (In.)
1.25
Tongue Width (In.)
0.71
Overall Length (In.)
2.4
Copper Code Conductor Size (AWG)
36617
Overall Length (mm)
60.5
Tongue Width (mm)
18
Stud Hole Size (In.)
45062
Stud Hole Size (mm)
7.9
Barrel Length (In.)
1.19
Wire Strip Length (mm)
31.8
Barrel Length (mm)
30.2
Tongue Thickness (In.)
0.18
Tongue Thickness (mm)
3.6

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Color Code
Purple
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Tool Type
Tin-Plated Copper Compression Connectors - Lugs
Tongue Style
Narrow
Hole Center to Center
44697
Tongue Type
Narrow
Burndy Die Index Number
15
Panduit Die Index Number
P54
Finish/Coating
Tin-Plated
Product Type
Copper Compression Connectors - Lugs
Maximum Voltage (kV)
35
UL Temperature Rating (°C)
90
T & B Die Index Number
54
Base Material
Copper
Product Class
Wire Termination

Description

One-hole, standard barrel with window, narrow tongue lug, 4/0 AWG wire, 5/16 stud hole.
