  6. Two-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black
Panduit Two-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black LCDX2/0-38D-X - main

Two-Hole Compression Lug, 2/0 AWG Max, Standard Barrel, Copper, Black

  • Mfr # LCDX2/0-38D-X

  • Zoro # G0777968

product price:  $13.59
/ea

Key Features

For Wire Size
2/0 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Standard
Tongue Width
0.96 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LCDX2/0-38D-X
Zoro #
G0777968
UPC #
7498342382
Country of Origin
Mexico

Dimensions

For Wire Size
2/0 AWG
Barrel Size
Standard
Tongue Width
0.96 in
Length
3.03 in
Width
0.96 in
Cable Size
2/0 AWG
Overall Length
3.03 in
Stud Hole Size (In.)
44993
Class G Copper Flex Conductor Size (AWG)
36557
Class M Copper Flex Conductor Size (AWG)
36557
Tongue Thickness (mm)
3.3
Stud Hole Size (mm)
9.5
Overall Length (mm)
77
Class H Copper Flex Conductor Size (AWG)
36557
Class I Copper Flex Conductor Size (AWG)
36557
Wire Strip Length (mm)
22
Barrel Length (In.)
0.83
Barrel Length (mm)
21.1
Copper Code Conductor Size (AWG)
36557
DLO Copper Flex Conductor Size (AWG)
36557
Tongue Thickness (In.)
0.13
Tongue Width (mm)
24.4
Wire Strip Length (In.)
45115
Overall Length (In.)
3.03
Tongue Width (In.)
0.96
Class K Copper Flex Conductor Size (AWG)
36557

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
13
Color Code
Black
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connector Type
Standard Barrel
Color
Black
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant
Base Material
Copper
Burndy Die Index Number
13
Panduit Die Index Number
P45
Stud Hole Spacing (mm)
25.4
T & B Die Index Number
45
Finish/Coating
Tin-Plated
UL Temperature Rating (°C)
90
Stud Hole Spacing (In.)
1
Product Type
Compression Connectors - Lugs
Tongue Type
Standard
Maximum Voltage (kV)
35
Product Color
Black
Product Name
Terminal Connector
Connector Plating
Tin
Connector Details
1 x Terminal
Product Material
Copper
Product Class
Wire Termination

Description

Lug Compression Connector,2/0 AWG
