  11. Two-Hole Compression Lug, 350 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Red
Panduit Two-Hole Compression Lug, 350 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Red LCD350-12-X - main

Two-Hole Compression Lug, 350 kcmil Max, 1 to 2 in Stud, Standard Barrel, Copper, Red

  • Mfr # LCD350-12-X

  • Zoro # G0777581

product price: $26.39
/ea

Key Features

Cable Size
350 kcmil
Connector Type
Standard Barrel
Width
1.28"
Material
Copper
Length
4.96"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCD350-12-X
Zoro #
G0777581
UPC #
7498390102
Country of Origin
Mexico

Dimensions

Cable Size
350 kcmil
Width
1.28"
Length
4.96"
Overall Length
4.96 in
Stud Hole Size (mm)
12.7
Barrel Length (mm)
36.6
Overall Length (In.)
4.96
Barrel Length (In.)
1.44
Wire Strip Length (In.)
1.5
Overall Length (mm)
126
Tongue Thickness (In.)
0.17
Wire Strip Length (mm)
38.1
Tongue Thickness (mm)
4.3
Tongue Width (In.)
1.28
Stud Hole Size (In.)
1 to 2
Tongue Width (mm)
32.5
Copper Code Conductor Size (kcmil)
350
Barrel Size
Standard
For Wire Size
350 kcmil
For Stud Size
1 to 2 in
Tongue Width
1.28 in

Details

Connector Type
Standard Barrel
Material
Copper
Color Code
Red
Item
Two-Hole Compression Lug
Die Code
18
Features
Corrosion Resistant
Connection Material
Tin
Connection Type
1 x Terminal
UL Temperature Rating (°C)
90
Stud Hole Spacing (mm)
44.5
Product Type
Copper Compression Connectors - Lugs
Base Material
Copper
Burndy Die Index Number
18
Panduit Die Index Number
P71
Stud Hole Spacing (In.)
1.75
Finish/Coating
Tin-Plated
Tongue Type
Standard
Tongue Angle
Straight
Maximum Voltage (kV)
35
Product Name
Terminal Connector
Product Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,350 Kcmil
