  11. Two-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray
Panduit Two-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray LCC4-14AWH-L - main

Two-Hole Compression Lug, 4 to 2 AWG Max, Long Barrel, Copper, Gray

  • Mfr # LCC4-14AWH-L

  • Zoro # G0775980

product price: $11.29
/ea

Key Features

Cable Size
4 to 3 AWG STR, 2 AWG SOL
Connector Type
Long Barrel
Width
0.55"
Material
Copper
Length
2.2"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCC4-14AWH-L
Zoro #
G0775980
UPC #
7498380767
Country of Origin
Mexico

Dimensions

Cable Size
4 to 3 AWG STR, 2 AWG SOL
Width
0.55"
Length
2.2"
Overall Length
2.2 in
Wire Strip Length (In.)
1.125
Stud Hole Size (In.)
44930
Tongue Thickness (In.)
0.09
Wire Strip Length (mm)
28.6
Tongue Width (In.)
0.55
Copper Code Conductor Size (AWG)
4
Barrel Length (In.)
1.05
Overall Length (In.)
2.2
Stud Hole Size (mm)
6.4
Barrel Length (mm)
26.7
Overall Length (mm)
55.9
Tongue Thickness (mm)
2.3
Tongue Width (mm)
14
For Wire Size
4 to 2 AWG
Tongue Width
0.55 in
Barrel Size
Long

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Gray
Item
Two-Hole Compression Lug
Die Code
8
Standards
CSA certified C22.2 No. 65-13, UL listed 486A-486B File #E52164
Connection Type
1 x Terminal
Connection Material
Tin
Features
45° Angled Connector, Corrosion Resistant
Tongue Type
Standard
Product Type
Copper Compression Connectors - Lugs
Finish/Coating
Tin-Plated
Stud Hole Spacing (In.)
0.63
Maximum Voltage (kV)
35
Tongue Angle
45 Degrees Angled
Burndy Die Index Number
8
T & B Die Index Number
29
Stud Hole Spacing (mm)
16
UL Temperature Rating (°C)
90
Panduit Die Index Number
P29
Base Material
Copper
Connector Details
1 x Terminal
Connector Plating
Tin
Product Material
Copper
Product Name
Terminal Connector
Product Class
Lugs, Splices, Split Bolts & Accessories
For Conductor Material
Copper

Description

Lug Compression Connector,4-3 AWG
