  11. Two-Hole Compression Lug, 500 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Brown
Panduit Two-Hole Compression Lug, 500 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Brown LCC500-12W-6 - main

Two-Hole Compression Lug, 500 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Brown

  • Mfr # LCC500-12W-6

  • Zoro # G0776017

product price: $36.29
/ea

Key Features

Cable Size
500 kcmil
Connector Type
Long Barrel
Width
1.54"
Material
Copper
Length
6.12"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LCC500-12W-6
Zoro #
G0776017
UPC #
7498379851
Country of Origin
Mexico

Dimensions

Cable Size
500 kcmil
Width
1.54"
Length
6.12"
Overall Length
6.12 in
Barrel Length (In.)
2.5
Copper Code Conductor Size (kcmil)
500
Outer Diameter (mm)
26.92
Tongue Width (In.)
1.54
Inside Diameter (In.)
0.84
Stud Hole Size (mm)
12.7
Wire Strip Length (In.)
42409
Overall Length (mm)
155.4
Outer Diameter (In.)
1.06
Wire Strip Length (mm)
65.1
Inside Diameter (mm)
21.33
Overall Length (In.)
6.12
Tongue Thickness (mm)
5.6
Tongue Thickness (In.)
0.22
Stud Hole Size (In.)
1 to 2
Tongue Width (mm)
39.1
Barrel Length (mm)
63.5
Tongue Width
1.54 in
For Wire Size
500 kcmil
Barrel Size
Long
For Stud Size
1 to 2 in

Details

Connector Type
Long Barrel
Material
Copper
Color Code
Brown
Item
Two-Hole Compression Lug
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Die Code
20
Connection Type
1 x Terminal
Connection Material
Tin
Features
Corrosion Resistant
Tongue Type
Standard
Maximum Voltage (kV)
35
Stud Hole Spacing (In.)
1.75
T & B Die Index Number
20
UL Temperature Rating (°C)
90
Base Material
Copper
Lug Type
2 Stud Hole Lug
Panduit Die Index Number
P87
Product Type
Copper Compression Connectors - Lugs
Burndy Die Index Number
20
Stud Hole Spacing (mm)
44.5
Finish/Coating
Tin-Plated
Tongue Angle
Straight
Product Material
Copper
Connector Plating
Tin
Connector Details
1 x Terminal
Product Name
Terminal Connector
Product Class
Mechanical & Compression Lugs & Splices
For Conductor Material
Copper

Description

Lug Compression Connector,500 Kcmil
