Two-Hole Compression Lug, 500 kcmil Max, 1 to 2 in Stud, Long Barrel, Copper, Pink

  • Mfr # LCCX500-12-6
  • Zoro # G0777091
product price:
$
62.39
/ea

Key Features

For Wire Size
500 kcmil
For Conductor Material
Copper
For Stud Size
1 to 2 in
Material
Copper
Barrel Size
Long
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LCCX500-12-6
Zoro #
G0777091
UPC #
7498343793
Country of Origin
Mexico

Dimensions

For Wire Size
500 kcmil
For Stud Size
1 to 2 in
Barrel Size
Long
Tongue Width
1.89 in
Width
1.89 in
Length
6.66 in
Cable Size
500 kcmil
Overall Length
6.66 in
Class K Copper Flex Conductor Size (kcmil)
500
Class M Copper Flex Conductor Size (kcmil)
500
Tongue Width (In.)
1.89
Tongue Thickness (mm)
6.6
Inside Diameter (mm)
26.16
Outer Diameter (mm)
33.02
Class G Copper Flex Conductor Size (kcmil)
500
Overall Length (In.)
6.66
Wire Strip Length (In.)
42415
DLO Copper Flex Conductor Size (kcmil)
535.3
Stud Hole Size (In.)
1 to 2
Class H Copper Flex Conductor Size (kcmil)
500
Tongue Thickness (In.)
0.26
Overall Length (mm)
169.2
Stud Hole Size (mm)
12.7
Barrel Length (mm)
73.2
Outer Diameter (In.)
1.3
Class I Copper Flex Conductor Size (kcmil)
500
Tongue Width (mm)
48
Barrel Length (In.)
2.88
Inside Diameter (In.)
1.03
Wire Strip Length (mm)
74.6

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
99
Color Code
Pink
Standards
C22.2 No. 65-13, 486A-486B File #E52164
Connector Type
Long Barrel
Features
Corrosion Resistant
Connection Type
1 x Terminal
Connection Material
Tin
Finish/Coating
Tin-Plated
Base Material
Copper
T & B Die Index Number
L99
Burndy Die Index Number
L99
Maximum Voltage (kV)
35
Panduit Die Index Number
P99
Product Type
Copper Compression Connectors - Lugs
UL Temperature Rating (°C)
90
Tongue Type
Standard
Stud Hole Spacing (mm)
44.5
Lug Type
2 Stud Hole Lug
Stud Hole Spacing (In.)
1.75
Product Name
Terminal Connector
Product Material
Copper
Connector Plating
Tin
Connector Details
1 x Terminal
Product Class
Wire Termination

Description

Lug Compression Connector,500 Kcmil

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
