Two-Hole Compression Lug, 6 AWG Max, Long Barrel, Copper, Blue
- Mfr # LCCX6-14D-L
- Zoro # G0417625
product price:Â
$
8.29
/ea
Key Features
For Wire Size
6 AWG
For Conductor Material
Copper
Material
Copper
Barrel Size
Long
Tongue Width
0.48 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- LCCX6-14D-L
- Zoro #
- G0417625
- UPC #
- 7498342539
- Country of Origin
- Mexico
- Item
- Two-Hole Compression Lug
- For Conductor Material
- Copper
- Material
- Copper
- Tongue Angle
- Straight
- Die Code
- 7
- Color Code
- Blue
- Connector Type
- Long Barrel
- Connection Material
- Tin
- Connection Type
- 1 x Terminal
- Features
- Corrosion Resistant
- Maximum Voltage (kV)
- 35
- Tongue Type
- Standard
- Panduit Die Index Number
- P24
- Product Type
- Compression Connectors - Lugs
- Finish/Coating
- Tin-Plated
- Burndy Die Index Number
- 7
- Stud Hole Spacing (mm)
- 25.4
- Stud Hole Spacing (In.)
- 1
- UL Temperature Rating (°C)
- 90
- Product Name
- Terminal Connector
- Connector Plating
- Tin
- Connector Details
- 1 x Terminal
- Product Material
- Copper
- Product Class
- Wire Termination
Dimensions
- For Wire Size
- 6 AWG
- Barrel Size
- Long
- Tongue Width
- 0.48 in
- Cable Size
- 6 AWG
- Width
- 0.48 in
- Length
- 2.86"
- Overall Length
- 2.86 in
- Class M Copper Flex Conductor Size (AWG)
- 6
- Class I Copper Flex Conductor Size (AWG)
- 6
- Copper Code Conductor Size (AWG)
- 6
- Tongue Width (In.)
- 0.48
- Overall Length (mm)
- 72.6
- Wire Strip Length (mm)
- 29
- Tongue Width (mm)
- 12.2
- Class H Copper Flex Conductor Size (AWG)
- 6
- Stud Hole Size (In.)
- 44930
- Wire Strip Length (In.)
- 1.13
- Barrel Length (mm)
- 27.2
- Overall Length (In.)
- 2.86
- Barrel Length (In.)
- 1.07
- Class G Copper Flex Conductor Size (AWG)
- 6
- Tongue Thickness (In.)
- 0.08
- Tongue Thickness (mm)
- 2
- Stud Hole Size (mm)
- 6.4
- DLO Copper Flex Conductor Size (AWG)
- 6
- Class K Copper Flex Conductor Size (AWG)
- 6
Description
Two-hole, flex lug, long barrel, #6 AWG wire, 1/4 stud hole, 1 hole spacing.
