Air Brake Tubing, 1/2 In. OD, Orgn
Mfr # 1120-8B-ORG-100
Zoro # G3516877
product price:Â
$
217.99
/ea
Free Shipping & Returns
Key Features
Length
100 ft
Material
Nylon
Outside Dia.
1/2 in
Color
Orange
Type
Type B - Reinforced
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 1120-8B-ORG-100
- Zoro #
- G3516877
- UPC #
- -
- Country of Origin
- United States
- Item
- Tubing
- Material
- Nylon
- Color
- Orange
- Type
- Type B - Reinforced
- Temp. Range
- -40 Degrees to 200 Degrees F
- Standards
- DOT FMVSS106, SAE J1131, SAE J844
- Max. Working Pressure
- 150 psi
- Application
- Air Brake Harness, Formed Air Brake Harness Assemblies, Formed Tubes, Trailer Air Brake Systems, Truck Air Brake and Auxiliary Air Systems
- Product Type
- Air Brake Tubing
- Jacket Color
- No Jacket
- Jacket Material
- No Jacket
- Maximum Working Pressure
- 150 psi
- Includes Fittings
- No
- Resistance Properties
- Abrasion Resistant,Chemical Resistant,Corrosion Resistant,Crack Resistant,Flame Resistant,Freeze Resistant,Fuel Resistant,Grease Resistant,Hardening Resistant,Heat Resistant,High Temperature Resistant,Humidity Resistant,Kink Resistant,Low Temperature Resistant,Non-Conductive,Non-Flammable,Oil Resistant,Road Salt Resistant,Salt Water Resistant,Tear Resistant,Temperature Resistant,UV Resistant,Wear Resistant,Weather Resistant
- Temperature Range
- -40 Degrees to 200 Degrees F
- Air Brake Type
- Type B
- Tube Material
- Nylon
- Maximum Operating Temperature
- 200 Degrees F
- Reinforcement
- Polyester Braid
- Weight per Foot
- 0.039 lb/ft
- Minimum Operating Temperature
- -40 Degrees F
Description
Tubing, Product Type Air Brake Tubing, Air Brake Type Type B, Application Air Brake Harness, Formed Air Brake Harness Assemblies, Formed Tubes, Trailer Air Brake Systems, Truck Air Brake and Auxiliary Air Systems, Bend Radius 2 in, Coiled Air Tube Application Not Applicable, Color Orange, Maximum Operating Temperature 200 Degrees F, Includes Fittings No, Fitting Side A Material Not Applicable, Specific Fitting Side A Shape Not Applicable, Fitting Side A Gender Not Applicable
