Air Cylinders
- Mfr # 0.75DSRD02.00
- Zoro # G022886917
product price:Â
$
53.99
/ea
Key Features
For Fluid Type
Dry, Filtered Air
Minimum Operating Temperature
32 Degrees F
Cylinder Type
Round Body
System of Measurement
Inch
Air Inlet Type
NPT
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 0.75DSRD02.00
- Zoro #
- G022886917
- UPC #
- -
- Country of Origin
- United States
- For Fluid Type
- Dry, Filtered Air
- Minimum Operating Temperature
- 32 Degrees F
- Cylinder Type
- Round Body
- System of Measurement
- Inch
- Air Inlet Type
- NPT
- Spring Retraction Force
- 6 lb
- Piston Material
- Aluminum
- Item
- Round Air Cylinder
- Maximum Operating Pressure
- 100 psi
- Number of Rods
- Single Rod
- Rod Gender
- Male
- Maximum Operating Temperature
- 160 Degrees F
- Body Material Grade
- 304
- Spring Extension Force
- 6 lb
- Cushion Type
- None
- Magnetic Piston
- Non-Magnetic Piston
- Body Material
- Stainless Steel
- Rod Rotation
- Rotating Rod
- Cylinder Repair
- Non-Repairable
- Series
- SRD
Dimensions
- Nose Mount Thread Size
- 5/8"-18
- Inlet Size
- 1/8"
- Stroke Length
- 2 in
- Body Diameter
- 7/8 in
- Rod Diameter
- 1/4 in
- Rod Thread Size
- 1/4"-28
- Rod Thread Length
- 1/2 in
- Bore Diameter
- 3/4 in
Description
Round Air Cylinder, Body Material Stainless Steel, Cylinder Type Round Body, Cylinder Repair Non-Repairable, Magnetic Piston Non-Magnetic Piston, Mounting Type Nose, Bore Diameter 3/4 in, Cushion Type None, Stroke Length 2 in, Inlet Size 1/8 In., Air Inlet Type NPT, Spring Retraction Force 6 lb, Cylinder Action Double Acting, Number of Rods Single Rod, System of Measurement Inch, Body Material Grade 304, Body Diameter 7/8 in, Inlet Gender Female, Maximum Operating Pressure 100 psi
