  11. Colorflow Needle Valve, Steel, 1/4-18, 5 GPM, 5000 PSI
Shop All Hydraulic Control Valves
Parker

Colorflow Needle Valve, Steel, 1/4-18, 5 GPM, 5000 PSI

product price: $68.89
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Valve Type - Hydraulic Valves Hydraulic Needle Valve
  • Body Material Steel
  • Inlet Port Size - Hydraulic Valves 1/4 in NPT
  • Outlet Port Size - Hydraulic Valves 1/4 in NPT
  • Body Material - Hydraulic Valves Steel
See all product information

Product Information

Dimensions

Inlet Port Size - Hydraulic Valves 1/4 in NPT
Outlet Port Size - Hydraulic Valves 1/4 in NPT
Length (In.) 2.0 in
Height (In.) 1.79 in
Overall Length 2 in
Overall Width 0.81 in
Overall Height 2.195 in
Port-to-Port Length 2 in
Inlet Connection Dash Size 18
Inlet Connection Size 1/4 in
Outlet Connection Dash Size 18
Outlet Connection Size 1/4 in

Details

Item Needle Valve
Valve Type - Hydraulic Valves Hydraulic Needle Valve
Body Material Steel
Body Material - Hydraulic Valves Steel
Max. Flow - Hydraulic Valves 5 gpm
Max. Pressure - Hydraulic Valves 5,000 psi
Type Steel
Reverse Free Flow No
Max. Pressure (PSI) 5000
Port (In.) 1/4-18
Flow Range (GPM) 5
Seal Material Nitrile
Series N
Valve Type Needle
Includes Seals Seals Included
Operating Temperature - Minimum -40 Degrees F
Control Direction One-Way
Mounting Inline
Inlet Connection Gender Female
Outlet Connection Gender Female
Outlet Connection Type NPT
Adjustment Method Rotary Knob
Pressure - Maximum 5,000 psi
Inlet Connection Type NPT
Valve Control Flow Control
Operating Temperature - Maximum 250 Degrees F
Coefficient of Volume (Cv) 0.443
Flow Rate - Maximum 5 gpm
For Media Oil
Actuation Mechanism Manual

Description

Needle Valve, Flow Rate - Maximum 5 gpm, Valve Type Needle, Pressure - Maximum 5,000 psi, Body Material Steel, Inlet Connection Type NPT, Outlet Connection Type NPT, Adjustment Method Rotary Knob, Actuation Mechanism Manual, Inlet Connection Gender Female, Outlet Connection Gender Female, Includes Seals Seals Included, Seal Material Nitrile, Inlet Connection Dash Size 18, Control Direction One-Way, Coefficient of Volume (Cv) 0.443, For Media Oil, Inlet Connection Size 1/4 in, Mounting Inline
