Coupler Plug, Steel, Hose Barb, 25 cfm
Mfr # 8C
Zoro # G4874825
Key Features
Specifications
Product Information
- MFR #
- 8C
- Zoro #
- G4874825
- UPC #
- -
- Country of Origin
- United States
Dimensions
- Hose Fitting Size
- 1/4 in
- Coupling Size
- 1/4 in
- Barb Size
- 1/4 in
- Overall Length
- 1 5/8 in
- Body Size - Quick Connect Air Couplings
- 1/4 in
- Max. Outside Dia.
- 7/16 in
- Wire Rope Length
- 1 5/8 in
- Length
- 1 5/8 in
Details
- Item
- Quick Connect Air Coupling
- Interchange Type
- Tru-Flate-Automotive
- Material
- Steel
- Coupling Component
- Plug
- Hose Fitting Gender
- Male
- Connection Type
- Hose Barb
- Finish/Coating
- Trivalent Chrome
- Max. Flow Rate
- 707.92 lpm
- Coupling Locking Type
- Sleeve
- Includes Valve
- No
- Color
- Silver
- Temp. Range
- -40 Degrees to 250 Degrees F
- Application
- Pneumatic
- Max. Working Pressure @ 70 F
- 300 psi
- For Hose I.D.
- 1/4 in
- Barbed
- Yes
Description
The PARKER - 8C is a hose coupling for pneumatic applications. It supports connection and disconnection using a sleeve locking mechanism without tools, intended to form a connection within the specified pressure and temperature ranges. The coupling features a male hose barb connection and is intended for use with hoses that have a 1/4 in inner diameter. The steel fitting has a trivalent chrome coating and is rated for operation within a temperature range of -40°F to 250°F, with a rated maximum working pressure of 300 psi at 70°F. Its overall length measures 1.625 in, and it supports a maximum volumetric flow rate of 707.92 lpm.
Key Features:
- Application: Pneumatic systems
- Coupling type: Plug with sleeve locking mechanism
- Hose barb connection with 1/4 in barb size matching 1/4 in hose I.D.
- Material: Steel with trivalent chrome coating
- Hose fitting gender: Male
- Maximum working pressure: 300 psi at 70°F
- Maximum volumetric flow rate: 707.92 lpm
- Temperature operating range: -40°F to 250°F
- Overall length: 1 5/8 in (1.625 in)
- Maximum outside diameter: 7/16 in
- Interchange type: Tru-Flate-Automotive
