NO C08 POPPET SOLENOID 2P2W
Mfr # DSL081NR
Zoro # G115920979
product price:Â
$
81.19
/ea
Key Features
Body Material
Steel
Overall Height
3.46 in
Overall Length
2.47 in
Overall Width
1.33 in
Series
DSL081
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- DSL081NR
- Zoro #
- G115920979
- UPC #
- -
- Country of Origin
- Mexico
- Item
- Poppet Valve
- Body Material
- Steel
- Series
- DSL081
- Number of Positions
- Two Positions
- Standards
- ISO 4406 18/16/13, SAE Class 4
- Number of Ways
- Two-Way
- Fluid Viscosity - Maximum
- 2,000 SUS
- Operating Temperature - Minimum
- -35 Degrees F
- Body Finish
- Zinc Plated
- Operating Temperature - Maximum
- 200 Degrees F
- Actuation Mechanism
- Electrical
- Mounting
- Screw-In
- Flow Rate - Maximum
- 8 gpm
- Return Mechanism
- Solenoid
- Control Direction
- One-Way with Reverse Flow
- Includes Seals
- Seals Included
- Valve Action
- Normally Open
- Action Type
- Direct Acting
- Seal Material
- Polyurethane
- Cartridge Material
- Steel
- Pressure Setting - Maximum
- 3,000 psi
- Valve Type
- Poppet-Type Solenoid Valve
Description
Poppet Valve, Body Material Steel, Number of Positions Two Positions, Valve Action Normally Open, Adjustment Method Not Applicable, Number of Ways Two-Way, Valve Cavity Size C08-2, Actuation Mechanism Electrical, Overall Length 2.47 in, Overall Width 1.33 in, Overall Height 3.46 in, Flow Rate - Maximum 8 gpm, Voltage Not Applicable, Pressure Setting - Maximum 3,000 psi, Port Connection Dash Size 8, Center Position Not Applicable, Port Connection Type Not Applicable
