Quick Connect Socket, Steel, 1 11/16" L
Mfr # 25SFTF06SXZ
Zoro # G610831879
product price:
$
12.29
/ea
Sold in multiples of 10 for $122.90
Key Features
Interchange Type
European High Flow
Material
Steel
Coupling Component
Plug
Hose Fitting Gender
Male
Connection Type
Hose Barb
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- 25SFTF06SXZ
- Zoro #
- G610831879
- UPC #
- -
- Country of Origin
- Germany
Dimensions
- Hose Fitting Size
- 1/4 in
- Barb Size
- 1/4 in
- Overall Length
- 1 11/16 in
- Body Size - Quick Connect Air Couplings
- 1/4 in
- Max. Outside Dia.
- 1/2 in
- Wire Rope Length
- 1 11/16 in
- Length
- 1 11/16 in
Details
- Item
- Quick Connect Air Coupling
- Interchange Type
- European High Flow
- Material
- Steel
- Coupling Component
- Plug
- Hose Fitting Gender
- Male
- Connection Type
- Hose Barb
- Finish/Coating
- Zinc-Plated
- Max. Flow Rate
- 110 scfm
- Coupling Locking Type
- Ball
- Seal Material
- Nitrile
- Includes Valve
- No
- Temp. Range
- -4 Degrees to 212 Degrees F
- Includes
- (4) Locking Balls
- Valve Type
- Aerodynamic
- For Hose I.D.
- 1/4 in
- Max. Working Pressure @ 70 F
- 300 psi
- Barbed
- Yes
Description
The PARKER - 25SFTF06SXZ is a quick connect socket designed as the female half of a quick-connect coupling system. It accepts and locks a matching plug to form a sealed coupling when properly connected to a matching plug for pneumatic, hydraulic, or general fluid applications. This socket uses a push-to-connect action combined with a ball locking mechanism and an aerodynamic valve to be compatible with push-to-connect hookup and disconnection while intended to reduce leakage when properly connected. Made of steel with a zinc-plated finish, it features a 1/4 inch hose barb connection suitable for hoses with a 1/4 inch inner diameter.
Key Features:
- Hose connection type: Hose Barb with a 1/4 in barb size
- Hose fitting gender: Male, with a hose fitting size of 1/4 in
- Seal material: Nitrile for fluid tightness
- Temperature range: rated for operation within a temperature range of -4°F to 212°F
- Coupling locking type: Ball mechanism
- Finish coating: Zinc Plated
- Overall length: 1.69 in (1 11/16 in)
- Includes (4) Locking Balls
- Interchange type: European High Flow
