Shop PATTERSON

MountedFan, Black, 9-1/2inDia, Aluminum

  • Mfr # FHVTCD-IDL-Y-1003

  • Zoro # G316539130

product price:  $1,470.99
/ea
Free Shipping & Returns

Key Features

Oscillation
Non-Oscillating
Sound Level
75 dBA
Guard Material
Steel
Air Velocity @ 20 Ft.
250 fpm
Shaft Dia.
5/8 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
FHVTCD-IDL-Y-1003
Zoro #
G316539130
UPC #
-
Country of Origin
United States

Dimensions

Shaft Dia.
5/8 in
Max. Mounting Height
9 ft
Width
16 in
Fan Cord Length
14 ft
Height
17 1/2 in
Height Adjustment
8 feet
Blade Diameter
9 1/2 in
Depth
26 in

Details

Item
Mounted Fan
Oscillation
Non-Oscillating
Sound Level
75 dBA
Guard Material
Steel
Air Velocity @ 20 Ft.
250 fpm
Number of Speeds
1
Voltage
277V AC
Features
Dock and Trailer Cooling Fan, Low Profile, Quiet, Contnuous Duty Rated
Air Velocity @ 40 Ft.
250 fpm
Air Velocity @ 10 Ft.
250 fpm
Drive Type
Direct Drive
Bearing Type
Ball
For Location
Warehouse
Assembly Required
No
Watts
720 W
Hz
60 Hz
RPM
1,075 RPM
Housing Finish - Fans
High Impact Yellow Polypropylene
Airflow
3,200 cfm
NEMA Plug Configuration
HardWire
Fan Blade Color
Black
Blade Material
Aluminum
Mount Type
Arm
Bearing Protection
Sealed
Amps
2.6
Wire Guard Finish
Chrome-Plated
Standards
OSHA Compliant Guards
Motor HP
1/2 hp
Motor Enclosure
Open Drip Proof
Includes
Ships with Mounting Yoke and Integral dock light
Environmental Applications
Commercial, Industrial
Fan Power Source
Hardwired
Max. Ambient Temp.
104 Degrees F
Motor Insulation
A
Head Tilt Adjustment
30 Degrees
Number of Conductors
3
Thermal Protection
Automatic Reset
Color
Yellow

Description

Mounted Fan, Non-Oscillating, Voltage 277V AC, 1 Phase, Air Velocity @ 20 Ft. 250 fpm, Motor HP 1/2 hp, Fan Mounting Location Wall, Sound Level 75 dBA, Max. Ambient Temp. 104 Degrees F, Hz 60 Hz, Watts 720 W, Motor Type Permanent Split Capacitor, Drive Type Direct Drive, Height 17 1/2 in, Width 16 in

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
