- MFR #
- GP 116 MIA 613 234 ASA SCC
- Zoro #
- G7414937
- UPC #
- -
- Country of Origin
- United States
- Electrical/Mechanical
- Mechanical
- Lockset Handle Type
- Lever
- Mortise / Cylindrical
- Cylindrical
- Lockset Function
- Entrance
- Lockset Grade
- 2
- Style
- MIA Straight
- Lockset Finish
- Oil Rubbed Bronze
- Keyway Type
- Schlage C
- Key Type
- Keyed Different
- Ligature Resistant
- No
- For Use With
- Metal or Wood Doors
- Mortise/Cylindrical
- Cylindrical
- Strike Dim.
- 4-7/8 in x 1-1/4 in
- Lockset Performance Strength
- Medium Duty
- Series
- GP
- Standards
- ANSI/BHMA 156.2, Grade 2, ICC/ANSI 117.1
- Number of Keys
- 2
- Location Type
- Commercial
- Lockset Fire Rating
- 3 hr
- Strike Type
- ASA
- Features
- 1,500 lbf-in Lever Torque Resistance, 13 ga Steel Anti-Rotation Plate
- Number of Pins
- 6
- Cylinder Core Type
- Conventional Core Cylinder
- Key Material
- Brass
- Item
- Door Lockset
- Handle Material
- Zinc
- ADA Compliant
- Yes
- Backset
- 2 3/4 in
- Visual Indicator Message
- No Message
- Fire Rating
- 3 hr
- Latch Bolt/Dead Bolt
- Latch Bolt
- Locking/Unlocking Access - Outside
- Keyway
- Trim Plate Shape
- Round
- Includes Core
- Core Included
- ANSI Grade
- 2
- Performance Grade
- 1
- Locking/Unlocking Access - Inside
- Push Button
- ANSI/BHMA Finish
- Dark Oxidized Satin Bronze, Oil Rubbed
- Knob/Handle Material
- Bronze
- Lockset Style
- Miami Lever
- UL Fire Rating
- UL10C
- Lockset Type
- Mechanical
- Application
- Educational, Government, Institutional, Hospitals, Churches, Industrial, Multiple Family Residential, Office
- Hand Orientation
- Non-Handed
- Ligature-Resistant
- Not Ligature-Resistant
- Lockset Function ANSI Code
- F109
