Low Pressure Gauge, 0 to 100 psi, 4 in Dial, 1/2 in NPT, Bottom Location

  • Mfr # LP1-SS-402-100

  • Zoro # G6507846

product price:
$
113.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-2-1-2%
Process Connection Location
Bottom
Process Connection Size
1/2 in
Process Connection Type
NPT
Dial Size (In.)
4 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LP1-SS-402-100
Zoro #
G6507846
UPC #
-
Country of Origin
China

Dimensions

Process Connection Size
1/2 in
Dial Size (In.)
4 in
Length
5.30"
Case Depth
1.91 in
Case Diameter
4.375 in
Nominal Dial Size
4 in
Manufacturer Warranty Length
1 yr
Nominal Dial Diameter
4 in

Details

Item
Low Pressure Gauge
Accuracy
+/-2-1-2%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Industrial
Gauge Case Material
Stainless Steel
Series
LP1-SS
Lens Material
Heavy-Duty Glass
Primary Pressure Range
0 to 100
Primary Scale Units
in wc
IP/NEMA Rating
IP33
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Graduations
20 in wc
Gauge Primary Range Smallest Graduation
2
For Use With
Suitable for Air, Water, Oil, Gas or Any Other Media not Corrosive to Stainless Steel
Calibration Certificate Included
No
Case Color
Stainless Steel
Gauge Application
For Natural Gas & Other Gases
Smallest Graduation
2 in wc
Case Material
Stainless Steel
Socket Material
Stainless Steel
Includes
Vent Plug
Connection Type
MNPT
Standards
ASME
Wetted Materials
Stainless Steel
Includes Vent Plug
No
Dry Dampening Feature
None
Cleaned for Oxygen Service
No
Includes Calibration Certificate
No
Pressure Range Type
Pressure
Pressure Gauge Type
Low Pressure Gauge
Case Construction
Corrosion Resistant
Includes Mounting Hardware
No
Ambient Operating Temperature Range
-30 Degrees to 180 Degrees F
Removable Bezel
Yes
Primary Scale Minor Graduations
2
Scale Type
Single
Bezel Mounting Type
Removable
Compatible Process Media
Air, Gas, Oil, Water
Field Fillable
No
Sensor Type
Capsule
Process Connection Gender
Male
Bezel Material
Stainless Steel
Pointer Characteristics
Pointer Adjustable, Black Aluminum Adjustment Screw on Dial Face
Accuracy Scale
Mid-Scale
Vibration Resistance
None
Dial Color
White
Freeze Resistant Movement
No
Accuracy Grade
ASME B40.100 Grade A
Adjustable Pointer
No
Pointer Color
Black
Pointer Material
Aluminum
Gauge Case Liquid
None
Sensor Material
316 Stainless Steel
Operating Temperature Range
-30 Degrees to 180 Degrees F
Compatible with Series
LP1-SS
Compatible with Brand
Universal
Operating Temperature - Maximum
180 Degrees F
Secondary Scale Units
in wc
Primary Scale Pressure Measurement - Minimum
0 in wc
Operating Temperature - Minimum
-30 Degrees F
NEMA Enclosure Rating
No Enclosure
Process Media Temperature - Maximum
180 Degrees F
Process Media Temperature - Minimum
-30 Degrees F
Case Liquid
None
Primary Scale Pressure Measurement - Maximum
100 in wc

Description

Low Pressure Gauge, Nominal Dial Size 4 in, Accuracy +/-2-1-2 Percent, Gauge Case Material Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Heavy-Duty Glass, Process Connection Size 1/2 in, Field Fillable No, Process Connection Location Bottom, Case Color Stainless Steel, IP/NEMA Rating IP33, Primary Pressure Range 0 to 100, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge
