  5. Low Pressure Gauge, 0 to 30 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location
Pic Gauges Low Pressure Gauge, 0 to 30 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location LP1-SS-254-30 - main

Low Pressure Gauge, 0 to 30 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location

  • Mfr # LP1-SS-254-30

  • Zoro # G6579903

product price:  $164.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-2-1-2%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
LP1-SS-254-30
Zoro #
G6579903
UPC #
-
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Length
3.55"
Manufacturer Warranty Length
1 yr
Nominal Dial Size
2 1/2 in
Case Diameter
2.937 in
Case Depth
1.81 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-2-1-2%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Industrial
Gauge Case Material
Stainless Steel
Series
LP1-SS
Lens Material
Heavy-Duty Glass
Primary Pressure Range
0 to 30
Primary Scale Units
in wc
IP/NEMA Rating
IP33
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Smallest Graduation
0.5 in wc
Calibration Certificate Included
No
Case Color
Stainless Steel
For Use With
Suitable for Air, Water, Oil, Gas or Any Other Media not Corrosive to Stainless Steel
Graduations
5 in wc
Gauge Application
For Natural Gas & Other Gases
Gauge Primary Range Smallest Graduation
0.5
Socket Material
Stainless Steel
Case Material
Stainless Steel
Includes
Vent Plug
Standards
ASME
Connection Type
MNPT
Wetted Materials
Stainless Steel
Field Fillable
No
Gauge Case Liquid
None
Pointer Material
Aluminum
Dial Color
White
Compatible Process Media
Air, Gas, Oil, Water
Sensor Material
316 Stainless Steel
Primary Scale Minor Graduations
0.5
Pressure Range Type
Pressure
Accuracy Grade
ASME B40.100 Grade A
Pointer Characteristics
Pointer Adjustable, Black Aluminum Adjustment Screw on Dial Face
Dry Dampening Feature
None
Bezel Mounting Type
Removable
Pressure Gauge Type
Low Pressure Gauge
Bezel Material
Stainless Steel
Includes Vent Plug
No
Includes Calibration Certificate
No
Case Construction
Corrosion Resistant
Accuracy Scale
Mid-Scale
Sensor Type
Capsule
Adjustable Pointer
No
Pointer Color
Black
Ambient Operating Temperature Range
-30 Degrees to 180 Degrees F
Vibration Resistance
None
Process Connection Gender
Male
Freeze Resistant Movement
No
Cleaned for Oxygen Service
No
Removable Bezel
Yes
Scale Type
Single
Includes Mounting Hardware
No
Operating Temperature Range
-30 Degrees to 180 Degrees F
Primary Scale Pressure Measurement - Minimum
0 in wc
Compatible with Series
LP1-SS
Primary Scale Vacuum Measurement - Maximum
30 in wc
Operating Temperature - Minimum
-30 Degrees F
Case Liquid
None
NEMA Enclosure Rating
No Enclosure
Compatible with Brand
Universal
Primary Scale Pressure Measurement - Maximum
30 in wc
Process Media Temperature - Minimum
-30 Degrees F
Operating Temperature - Maximum
180 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 in wc
Process Media Temperature - Maximum
180 Degrees F
Secondary Scale Pressure Measurement - Maximum
17.5 in wc
Secondary Scale Units
in wc

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-2-1-2 Percent, Gauge Case Material Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Heavy-Duty Glass, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Stainless Steel, IP/NEMA Rating IP33, Primary Pressure Range 0 to 30, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge
