Pic Gauges Vacuum Gauge, 1/8 in. NPT, 1-1/2in 201L-158A - main

Vacuum Gauge, 1/8 in. NPT, 1-1/2in

  • Mfr # 201L-158A

  • Zoro # G5120389

product price: $19.15
/ea

Key Features

Pressure and Vacuum Gauge Type
Vacuum Gauge
Gauge Application
Corrosion-Resistant Case
Liquid Filled
Yes
Gauge Nominal Dial Size
1 1/2 in
Basic Gauge Case Material
Stainless Steel
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
201L-158A
Zoro #
G5120389
UPC #
-
Country of Origin
China

Dimensions

Gauge Nominal Dial Size
1 1/2 in
Gauge Connection Size
1/8 in
Connection Size
1/8 in NPT
Manufacturers Warranty Length
1 yr
Manufacturer Warranty Length
1 yr
Process Connection Size
1/8 in
Case Diameter
1.85 in
Nominal Dial Size
1 1/2 in
Case Depth
1 in
Nominal Dial Diameter
1 1/2 in

Details

Pressure and Vacuum Gauge Type
Vacuum Gauge
Gauge Application
Corrosion-Resistant Case
Liquid Filled
Yes
Basic Gauge Case Material
Stainless Steel
Basic Gauge Wetted Parts
Copper
Gauge Connection Type
MNPT
Gauge Connection Location
Bottom
Gauge Primary Range Units
in Hg
Gauge Sensor Material
Copper Alloy
Calibration Certificate Included
No
Basic Gauge Socket Material
Copper
Case Color
Metallic
Smallest Graduation
0.5 in Hg
Gauge Primary Range Values
-30 to 0
Basic Gauge Sensor Material
Copper
Gauge Primary Range Smallest Graduation
0.5
Gauge Socket Material
Copper Alloy
Range
30 in to 0 in Hg Vac
Gauge Panel Mountable
No
Item
Industrial Vacuum Gauge
Includes
Vent Plug
Gauge Case Color
Stainless Steel
Gauge Lens Material
Polycarbonate
Operating Temp. Range
30 Degrees to 160 Degrees F
Gauge Case Material
Stainless Steel
Gauge Filled With
Glycerin
Basic Gauge Lens Material
Plastic
Connection Location
Lower
Gauge Accuracy
+/-3-2-3%
Series
201L
Field Fillable
No
Pressure Range Type
Vacuum
Includes Vent Plug
Yes
Pointer Material
Aluminum
Removable Bezel
No
IP/NEMA Rating
Not Rated
Liquid-Filled Case
Yes
Lens Material
Polycarbonate
Standards
ASME
Non-Sparking
No
Accuracy
+/-3-2-3%
Case Construction
Stainless Steel
Bezel Mounting Type
Removable
Hazardous Location Rating
Not Rated
Pressure Gauge Type
Industrial Pressure Gauge
Vibration Resistance
Liquid-Filled
Primary Scale Minor Graduations
0.5
Process Connection Location
Bottom
Process Connection Gender
Male
Dial Color
White
Secondary Scale Units
bar
Gauge Case Liquid
Glycerin
Accuracy Scale
Mid-Scale
Process Connection Type
NPT
Scale Type
Dual
Primary Pressure Range
0 to 5,000
Application
General Purpose
Secondary Pressure Range
0 to 345 bar
Panel-Mountable
No
Accuracy Grade
ASME B40.100 Grade B
Dry Dampening Feature
None
Blowout Safety Back
No
Ambient Operating Temperature Range
30 Degrees to 160 Degrees F
Cleaned for Oxygen Service
No
Pointer Color
Black
Includes Calibration Certificate
No
Sensor Material
Copper Alloy
Includes Mounting Hardware
No
Dial Face Material
Aluminum
Primary Scale Units
psi
Case Material
Stainless Steel
Bezel Material
Stainless Steel
Freeze Resistant Movement
No
Socket Material
Copper Alloy
Primary Scale Vacuum Measurement - Maximum
0 psi
Primary Scale Pressure Measurement - Maximum
5,000 psi
Compatible with Series
201L
Operating Temperature - Maximum
160 Degrees F
NEMA Enclosure Rating
No Enclosure
Operating Temperature - Minimum
30 Degrees F
Compatible with Brand
Universal
Secondary Scale Pressure Measurement - Minimum
0 bar
Process Media Temperature - Minimum
30 Degrees F
Primary Scale Vacuum Measurement - Minimum
30 in Hg
Secondary Scale Pressure Measurement - Maximum
345 bar
Case Liquid
Glycerin
Secondary Scale Vacuum Measurement - Minimum
0 bar
Process Media Temperature - Maximum
160 Degrees F
Primary Scale Pressure Measurement - Minimum
0 psi

Description

Industrial Vacuum Gauge, Nominal Dial Size 1 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/8 in, Field Fillable No, Process Connection Location Bottom, Case Color Metallic, IP/NEMA Rating Not Rated, Primary Pressure Range 0 to 5,000, Dry Dampening Feature None, Vibration Resistance Liquid-Filled, Dial Color White
