Electric Operated Drum Pump, 12VDC, 9 Max. Flow Rate , Polyethylene

  • Mfr # F00102000

  • Zoro # G8500171


product price: $2,188.99
/ea
Item requires special delivery charges. A $105.00 per item surcharge will be applied.

Key Features

Voltage
12VDC
Application
Agriculture, Automotive, Fleet, Industrial, Marine, Off-Road
Housing Material
Polyethylene
GPM
9
Seal Material
NBR
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
F00102000
Zoro #
G8500171
UPC #
810015630525
Country of Origin
Italy

Dimensions

Manufacturers Warranty Length
2 yr. Manufacturing Defects
Hose Length
12 ft
Discharge Tube Length
20 ft.
Cord Length
72 in
Bung Connection Dia.
2 in
Hose Inside Dia.
3/4 in
For Container Size
55 gal
Hose Outside Dia.
1 1/8 in
Spout Discharge Size
3/5 in

Details

Voltage
12VDC
Application
Agriculture, Automotive, Fleet, Industrial, Marine, Off-Road
Housing Material
Polyethylene
GPM
9
Seal Material
NBR
Self-Priming
Yes
Max. Viscosity
1 cps
Item
Electric Operated Drum Pump
Features
COMPATIBLE WITH DEF
Adapter Type
1" BSP
Adapter Material
Stainless Steel
Includes
ADPATER, DELIVERY HOSE, DISCHARGE HOSE, METER, NOZZLE , PUMP, TANK
Agency Compliance
ISO 22241
Hose Material
EPDM
Max. Liquid Temp.
104 Degrees F
For Use With
Diesel Exhaust Fluid
Wetted Materials
Delrin, EPDM Nylon, NBR, Stainless steel
Motor Type
Brushed DC Motor
Metered
Yes
Motor Enclosure
OAO
Duty Cycle
Intermittent
Nozzle Material
Nylon, Stainless Steel, Viton
Includes Bung Adapter
Yes
Hose Tube Material
EPDM
Food Grade
No
Hose Cover Material
EPDM
Runs Dry
No
Series
NO
Max. Head Pressure
22 psi
Suction Tube OD
1 1/8 in
Includes Nozzle
Yes
Motor RPM
2,800 RPM
Thermal Protection
No
Pump Connection ID
1 in
Max. Fluid Temp.
104 Degrees F
Nozzle Operation
Automatic
Includes Suction Tube
Yes
Variable Speed
No
Suction Tube ID
3/4 in
Includes Discharge Hose
Yes
For Media Type
Antifreeze, DEF
Compatible Chemicals
Antifreeze (Coolant), DEF
Full Load Amps
22.0 A
Max. Flow Rate
9 gpm
Power Source
Electric
Max. Head - Pumps
45 ft
Includes Spout
Yes
Suction Tube Material
Polypropylene
Spout Material
Stainless Steel
Min. Fluid Temp.
12 Degrees F
For Container Type
Drum
Discharge Tube Outlet ID
3/4 in
Noise Level
75 db
Pump Connection OD
1 in
Diesel Exhaust Fluid Compatible
Yes
Pump Connection Type
Hose Barb
Housing Material - Pumps
Nylon
Discharge Tube Outlet OD
1 1/8 in
Motor HP
1/10 hp
Discharge Connection Type
Hose Barb
Grease
NT
Explosion Proof
No
Adapter Connection Type
Buttress
Max. Outlet Pressure
22 psi
Gear Lube
NT
Rated Voltage
12V DC

Description

Electric Drum Pump, Hose Inside Dia. 3/4 in, Max. Head Pressure 22 psi, Max. Outlet Pressure 22 psi, For Use With Diesel Exhaust Fluid, Rated Voltage 12 V DC, Pump Connection ID 1 in, Suction Tube OD 1 1/16 in, Hose Length 12 ft, Cord Length 72 in, Includes Bung Adapter Yes, Runs Dry No, Nozzle Operation Automatic, Thermal Protection No, Power Source Corded Electric, Variable Speed No, Includes Discharge Hose Yes, Self-Priming Yes, Compatible Chemicals Antifreeze (Coolant), DEF
