Multitap Connector, Aluminum, Gray, Hex, 3 Port

  • Mfr # IPLG1-3B

  • Zoro # G002714452

product price:  $35.29
/ea

Key Features

Connector Type
Single-Sided Entry
For Wire Size
2 AWG
Number of Ports
3
For Conductor Material
Copper
Body Material
Aluminum
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
IPLG1-3B
Zoro #
G002714452
UPC #
662381959492
Country of Origin
United States

Dimensions

For Wire Size
2 AWG
Hex Size
3/16 in
Stud Size
3/16 in
Wire Size
(Class B,C,D) 1-10 AWG - (Class K,M,I) 2-10 AWG
Min. Conductor Size
10 AWG
Max. Conductor Size
1 AWG; 2 AWG
Width
1.2 in
Length
1.6 in
Overall Width
1.24 in
For Stranded Copper Wire Size - Maximum
2 AWG
Overall Length
1.55 in
For Stranded Copper Wire Size - Minimum
10 AWG
Dimensions
L=1.550 - W=1.240 - H=1.370
Hex Wrench Size
3/16
Conductor Cu Size Range
1-10 AWG (CLASS B, C,D) & 2-10 AWG (Classes G, H, I, K, M, DLO)
Wire Rope Length
1.55 in

Details

Item
Multitap Connector
Connector Type
Single-Sided Entry
Number of Ports
3
For Conductor Material
Copper
Body Material
Aluminum
Insulation Material
Plastisol
Direct Burial Rated
No
Head Style
Hex
Finish
Plastisol
Color
Black
Maximum Operating Temperature
194 Degrees F
Standards
cULus
Material
Plastisol
Max. Voltage
600 V
No. of Ports
3
Type
Single-Sided Entry
Screw Material
Aluminum
RoHS Compliant
Yes
Maximum Voltage
600 V
Number Of Conductors
3
Application
Wire Termination
Standard
cULus
Temperature Rating
90° C
Voltage Rating
600 V
Environmental Conditions
90 C
Wire Type
B,C,D,K,M,I
Max Torque
150
Env Temp
Cold Temperature rated to -45C
Cu Conductor Max Amp
150
Conductors Count
3
Assortment
Fine Stranded Wire Pre-Insulated Connectors
Wire Cable Class
Class B, Class C, Class D, Class G, Class H, Class I, Class K, Class M, Class DLO
Ul File No
E186991
Temp Rating
90C, 9CU
Ul Standard
UL 486A/B

Description

Multitap Connector, Body Material Aluminum, Color Black, Finish Plastisol, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 10 AWG, For Stranded Copper Wire Size - Maximum 2 AWG, Head Style Hex, Hex Size 3/16 in, Insulation Material Plastisol, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Ports 3, UL 94 Flammability Rating Not Applicable, RoHS Compliant Yes, Standards cULus, Connector Type Single-Sided Entry, Direct Burial Rated No
