Non-Spring Return Actuator, 0-10VDC
Mfr # SAX61.03U
Zoro # G0114436
product price: $449.99
/ea
Free Shipping & Returns
Key Features
Fits Brand
Powers
Product Type
Electric Valve Actuator
Voltage
24V AC/DC
Stroke Length
20 mm
Compatible Valve Body Pattern
Two-Way
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
SAX61.03U
Zoro #
G0114436
UPC #
-
Country of Origin
Switzerland
Dimensions
Stroke Length
20 mm
Overall Width
4 7/8 in
Overall Height
9 1/2 in
Overall Depth
5 15/16 in
Details
Item
Electric Valve Actuator
Fits Brand
Powers
Product Type
Electric Valve Actuator
Voltage
24V AC/DC
Compatible Valve Body Pattern
Two-Way
Operating Temperature - Maximum
55 Degrees C
Frequency
50/60 Hz
Compatible Brand
Powers
Power Consumption
8 VA
Control Signal
Proportional
Cycle Time
30 sec
Compatible Valve Action
Normally Closed, Normally Open
Installation Orientation
Horizontal
Compatible Series
Flowrite 599
Operating Temperature - Minimum
-5 Degrees C
NEMA Rating
1
Return Action
Non-Spring Return
Description
Electric Valve Actuator, Compatible Brand Powers, Compatible Series Flowrite 599, Compatible Valve Action Normally Closed, Normally Open, Compatible Valve Body Pattern Two-Way, Control Signal Proportional, Cycle Time 30 sec, Frequency 50/60 Hz, Installation Orientation Horizontal, NEMA Rating 1, Operating Temperature - Maximum 55 Degrees C, Operating Temperature - Minimum -5 Degrees C, Overall Depth 5 15/16 in, Overall Height 9 1/2 in, Overall Width 4 7/8 in, Power Consumption 8 VA
