9 in., Diecast Aluminum, Surface Mount Right Hand Casement Operator (Single Pack)

This casement window operator is a right-handed, bronze, surface mount body type with four mounting holes in the top of the body and mounts directly onto the sill. It has a 9 in. steel arm with a round disc on the tip The disc slides in the Prime-Line part H 3595 casement track located on the bottom edge of the casement window. It is worm gear driven by a 3/8 in. crank spindle. The matching crank handle that fits onto the crank spindle and installation screws are included.

Constructed of diecast and steel material

Comes in a neutral gray color to blend with existing hardware, in a corrosion resistant, baked-on enamel finish

Designed for use with awning windows manufactured by various manufacturers

Features an L-shaped mounting hole pattern to provide greater stability when cranking

Easy to install with only a few simple tools

For further dimensional and specification information, please see the line drawing

A Phillips head screwdriver is required for Installation

For further dimensional information, please see the line drawing
