Trimline Cam Lock, 2-1/16 in. Hole Centers, Diecast, with lugs, White

This is a top mount bi-fold door pivot that is typically used on Alliance bi-fold doors. The spring loaded 1/4 in. steel pin inserts into a pre-drilled hole in the door and a top bracket above, creating a pivot point for your bi-fold door. Each steel pin is self-adjusting and features a mold injected clear plastic base. No fasteners are required for installation, but a soft mallet can be used with caution.

Used by Alliance and a variety of bi-fold door manufacturers

Top mount

3/8 in. diameter nylon base

Clear nylon base

No fasteners required

Grooved cone shaped pivot

Easy to install

For further dimensional information, please see the line drawing
