Cogetherm M Sheet, 1.500 X 40.000 X 48.000 ( Each)
Mfr # SCOGM1.500X40.000X48.000
Zoro # G400914379
product price:
$
7,589.99
/ea
Additional $200.00 delivery surcharge applies per item.
Key Features
Material
Cogetherm
Height
1.5
Length
48
Weight
235
Width
40
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- SCOGM1.500X40.000X48.000
- Zoro #
- G400914379
- UPC #
- -
- Country of Origin
- Multiple
- Material
- Cogetherm
- Weight
- 235
- Tensile Strength (psi @ 73 Deg;)
- 21750
- Dielectric Strength (volts/mil)
- 625
- Max. Recommended Use Temp (Deg:F)
- 932
- Flexural Strength (psi @ 73 Deg: F)
- 33350
- Specific Gravity (73 Deg: g/cm3)
- 2.15
- UL94 Flammability Rating Method: UL 94
- V-0
- Thermal Conductivity (BTU-in/ft²-hr-°F)
- 1.73
Description
Cogetherm® Mica plates for high-performance thermal and electrical insulation. Cogetherm is a mica laminate designed for electromechanical and thermomechanical applications. Cogetherm is made in two standard types: Cogetherm M (Muscovite) & Cogetherm P (Phlogopite) Cogetherm M, consists of +/-90% Cogemica Muscovite and +/-10% of bonding material. Cogetherm M has the highest resistance to pressure and is most recommended for complicated cut pieces. For continuous service temperature with temperatue up to 500° C (932° F), we recommend Cogetherm M. Cogetherm P, consists of +/-90%Cogemica-Phlogopite and +/-10% of bonding material. The resistance to pressure of Cogetherm P is less than M and it should be applied only for continous applications > 500° C (932°F) Both Cogetherm M & Cogetherm P are also available in a "desmoked" grade which emits reduced fumes during it's first applicaction. These grades are known as MC & PC. Standard Plate Size (untrimmed): 40" x 48" - which can be cut down to 20" x 24" sheets for shipping Thin Gauge Muscovite 505 & Muscovite 132 as well as Phlogopite 505 & Phlogopite 132 Sheets are produced in 39.27" x 23.62" & 47.24" x 39.29" Sheets.
