Product Information
MFR #
BNX40AC90-0804AX
Zoro #
G000953280
UPC #
-
Country of Origin
Unknown
Dimensions
Cable Diameter Range
3.2 “ 5.1 mm[.125 “ .2 in]
Cable Entry Diameter
.2 “ 6.4 mm[.01 “ .25 in]
Adapter Entry Size
4
Connector Shell Size
17,E
Details
Color
Bright
Adapter Plating Material
Electroless Nickel (AMS-C-26074)
Termination Device Type
Band Adapter,Band Strap
Adapter Angle
90
Operating Temperature Range
-65 “ 200 °C[-85 “ 392 °F]
Backshell Material
Aluminum
Salt Spray Resistance
48 Hr
TE Adapter Code
40
Overbraid Termination
Band
Connector Detail Specification Number
D38999/20, D38999/24, D38999/26, D38999/40, D38999/42, D38999/46, D38999/47
Pluggable I/O Accessory Type
Band
Connector General Specification Number
MIL-DTL-38999 Series III/Class C,F,K,W,MIL-DTL-38999 Series IV/Class C,F,W,MIL-DTL-38999 Series IV/Class C,W,MIL-DTL-38999 Series IV/Class F,W
