Product Information
MFR #
HET-A-02C
Zoro #
G000961773
UPC #
-
Country of Origin
Mexico
Dimensions
Cable Shield Diameter (Max)
5.3 mm[.21 in]
Cable Bundle Diameter (Max)
6.9 mm[.27 in]
Cable Size
Small
Cable Bundle Diameter (Min)
3.1 mm[.18 in]
Cable Shield Diameter (Min)
2.4 mm[.095 in]
Wire Bundle Diameter (Max)
4.2 mm[.165 in]
Details
Item
Butt Splice Wire Connector
Type
Butt Splice
Color
Blue
Insulation Material
Alloy
Minimum Operating Temperature
-65 Degrees C
Maximum Operating Temperature
175 Degrees C
Material
Radiation Cross-Linked Modified Polyvinylidene Fluoride
Finish
Electroless Nickel
Series
Raychem HET
Cable Type
Multi-Conductors Shielded,Single
Shield Plating Material
Pre-Tin
Ferrule Material
Copper Alloy
Shield Material
Copper Braid with Activated Rosin Flux
