Product Information
MFR #
TXR40AB45-1814AI
Zoro #
G800962734
UPC #
-
Country of Origin
United Kingdom
Dimensions
Cable Diameter Range
11.1 “ 17.8 mm[.438 “ .7 in]
Cable Entry Diameter
.2 “ 22.2 mm[.01 “ .88 in]
Adapter Entry Size
14
Connector Shell Size
19,F
Details
Color
Olive Drab
Overbraid Termination
Tinel-Lock Ring
Termination Device Type
Side-Entry Tinel-Lock Ring,Tinel-Lock Adapter,Tinel-Lock Ring
Salt Spray Resistance
500 Hr
Pluggable I/O Accessory Type
Tinel-Lock Adapter
Connector General Specification Number
MIL-DTL-38999 Series III/Class C,F,K,W,MIL-DTL-38999 Series IV/Class C,F,W,MIL-DTL-38999 Series IV/Class C,W,MIL-DTL-38999 Series IV/Class F,W
Termination Device Included
TR14AI
Backshell Material
Aluminum
Adapter Angle
45
Adapter Plating Material
Cadmium (AMS-QQ-P-416, Type II, Class 3)
Series
Raychem TXR
Operating Temperature Range
-65 “ 175 °C[-85 “ 347 °F]
Connector Detail Specification Number
D38999/20, D38999/24, D38999/26, D38999/40, D38999/42, D38999/46, D38999/47
TE Adapter Code
40
