Product Information
MFR #
TXR41AB00-2018AI
Zoro #
G800963212
UPC #
-
Country of Origin
United Kingdom
Dimensions
Adapter Entry Size
18
Cable Diameter Range
12.7 “ 20.5 mm[.5 “ .1 in]
Cable Entry Diameter
.2 “ 28.6 mm[.01 “ 1.13 in]
Connector Shell Size
20,21
Details
Color
Olive Drab
Adapter Angle
Straight
Series
Raychem TXR
Connector Detail Specification Number
MS24266, MS27467, MS27468, MS27472, MS27473, MS27474, MS27479, MS27480, MS27481, MS27484, MS27497, MS27652, MS27653, MS27656, MS27661, MS27665
Pluggable I/O Accessory Type
Tinel-Lock Adapter
Adapter Plating Material
Cadmium (AMS-QQ-P-416, Type II, Class 3)
Termination Device Type
Side-Entry Tinel-Lock Ring,Tinel-Lock Adapter,Tinel-Lock Ring
Salt Spray Resistance
500 Hr
Termination Device Included
TR18AI
Backshell Material
Aluminum
Connector General Specification Number
MIL-DTL-38999 Series I,MIL-DTL-38999 Series I/Class E,P,T,MIL-DTL-38999 Series I/Class E,T,MIL-DTL-38999 Series II/Class E,P,T,MIL-DTL-38999 Series II/Class E,T,MIL-DTL-38999 Series II/Class T
TE Adapter Code
41
Operating Temperature Range
-65 “ 175 °C[-85 “ 347 °F]
Overbraid Termination
Tinel-Lock Ring
