  11. TXR54SJ00-2820AI
This item is Discontinued.
Raychem TXR54SJ00-2820AI TXR54SJ00-2820AI

TXR54SJ00-2820AI (Discontinued)

  • Mfr # TXR54SJ00-2820AI
  • Zoro # G300963071
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TXR54SJ00-2820AI
Zoro #
G300963071
UPC #
-
Country of Origin
United States

Dimensions

Connector Shell Size
28
Cable Entry Diameter
.2 “ 31.8 mm[.01 “ 1.25 in]
Cable Diameter Range
12.7 “ 20.7 mm[.5 “ .12 in]
Adapter Entry Size
20

Details

Termination Device Type
Side-Entry Tinel-Lock Ring,Tinel-Lock Adapter,Tinel-Lock Ring
Series
Raychem TXR
Termination Device Included
TR20AI
Overbraid Termination
Tinel-Lock Ring
Adapter Plating Material
Passivated (SAE AMS-QQ-P-35 or MIL-S-5002)
Pluggable I/O Accessory Type
Tinel-Lock Adapter
TE Adapter Code
54
Connector General Specification Number
AS50151 Class D,L,U,W Crimp Contact,AS50151 Class D,L,U,W Crimp Contact Less ENDBELL,AS50151 Class L,W Crimp Contact,AS50151 Crimp Contact,AS81703 Series 3,AS81703 Series 3/Class E,L,MIL-DTL-26482 Series 2/Class A,L,MIL-DTL-83723 Series I/Class A,G,R,MIL-DTL-83723 Series I/Class G,R,MIL-DTL-83723 Series III/Class A,G,K,R,MIL-DTL-83723 Series III/Class A,G,K,R,S,MIL-DTL-83723 Series III/Class A,G,R,MIL-DTL-83723 Series III/Class G,R,MIL-DTL-83723 Series III/Class G,R,W,MIL-DTL-83723 Series III/Class S,MIL-DTL-83723 Series IIII/Class H
Adapter Angle
Straight
Backshell Material
Corrosion Resisting Steel
Salt Spray Resistance
1000 Hr
Operating Temperature Range
-65 “ 260 °C[-85 “ 500 °F]
Connector Detail Specification Number
AS34001, AS34011, AS34041, AS34061, AS34081, AS34091, AS34121, AS34241, AS34461, AS34501, AS34511, AS34541, AS34561, AS34641, AS34671, AS34681, M83723/01, M83723/02, M83723/03, M83723/04, M83723/05, M83723/06, M83723/07, M83723/08, M83723/13, M83723/14, M83723/36, M83723/37, M83723/38, M83723/39, M83723/40, M83723/41, M83723/42, M83723/43, M83723/48, M83723/49, M83723/65, M83723/66, M83723/67, M83723/68, M83723/69, M83723/71, M83723/72, M83723/73, M83723/74, M83723/75, M83723/76, M83723/77, M83723/78, M83723/82, M83723/83, M83723/84, M83723/85, M83723/86, M83723/87, M83723/91, M83723/92, M83723/95, M83723/96, M83723/97, M83723/98, MS3459, MS3470, MS3471, MS3472, MS3474, MS3475, MS3476, NAS 1599, NAS 1641, NAS 1642, NAS 1643, NAS 1650, NAS 1651, NAS 1652, NAS 1653, NAS 1692, NAS 1693, NAS 1694, NAS 1699, NAS 1700, NAS 1701, NAS 1702
